NTMFSC0D9N04CL
  • Share:

onsemi NTMFSC0D9N04CL

Manufacturer No:
NTMFSC0D9N04CL
Manufacturer:
onsemi
Package:
Tape & Reel (TR)
Description:
MOSFET N-CH 40V 8PQFN
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The NTMFSC0D9N04CL is a high-performance, low/medium voltage N-Channel MOSFET produced by onsemi. This device is housed in the Dualcool56 package, which is designed to provide excellent thermal performance and reliability. The MOSFET is characterized by its low on-resistance and high current handling capabilities, making it suitable for a variety of power management applications.

Key Specifications

Parameter Value Unit
VDS (Drain-Source Voltage) 40 V
ID (Continuous Drain Current) 313 A
RDS(ON) (On-Resistance) 0.9 mΩ
Package Type Dualcool56
Pins 8

Key Features

  • Low On-Resistance: The NTMFSC0D9N04CL features a low RDS(ON) of 0.9 mΩ, which minimizes power losses and enhances efficiency in power management applications.
  • High Current Handling: With a continuous drain current of 313 A, this MOSFET is capable of handling high current requirements.
  • Dualcool56 Package: The Dualcool56 package provides excellent thermal performance, ensuring reliable operation in demanding environments.
  • High Voltage Capability: The device can handle a drain-source voltage of up to 40 V, making it suitable for a wide range of power applications.

Applications

  • Power Supplies: The NTMFSC0D9N04CL is ideal for use in high-power DC-DC converters and power supplies due to its low on-resistance and high current handling.
  • Motor Control: This MOSFET is suitable for motor control applications, including electric vehicles and industrial automation.
  • Renewable Energy Systems: It can be used in solar and wind power systems to manage power efficiently.
  • Industrial Power Systems: The device is also applicable in various industrial power systems requiring high reliability and efficiency.

Q & A

  1. What is the maximum drain-source voltage of the NTMFSC0D9N04CL?

    The maximum drain-source voltage (VDS) is 40 V.

  2. What is the continuous drain current of the NTMFSC0D9N04CL?

    The continuous drain current (ID) is 313 A.

  3. What is the on-resistance of the NTMFSC0D9N04CL?

    The on-resistance (RDS(ON)) is 0.9 mΩ.

  4. In what package is the NTMFSC0D9N04CL available?

    The NTMFSC0D9N04CL is available in the Dualcool56 package.

  5. How many pins does the NTMFSC0D9N04CL have?

    The NTMFSC0D9N04CL has 8 pins.

  6. What are some typical applications of the NTMFSC0D9N04CL?

    Typical applications include power supplies, motor control, renewable energy systems, and industrial power systems.

  7. Why is the Dualcool56 package beneficial for this MOSFET?

    The Dualcool56 package provides excellent thermal performance, ensuring reliable operation in demanding environments.

  8. How does the low on-resistance benefit the performance of the NTMFSC0D9N04CL?

    The low on-resistance minimizes power losses and enhances efficiency in power management applications.

  9. Is the NTMFSC0D9N04CL suitable for high-power applications?

    Yes, the NTMFSC0D9N04CL is suitable for high-power applications due to its high current handling and low on-resistance.

  10. Where can I find detailed specifications for the NTMFSC0D9N04CL?

    Detailed specifications can be found on the onsemi official website, Digi-Key, and other authorized distributors.

Product Attributes

FET Type:N-Channel
Technology:MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):40 V
Current - Continuous Drain (Id) @ 25°C:313A (Tc)
Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
Rds On (Max) @ Id, Vgs:-
Vgs(th) (Max) @ Id:2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:143 nC @ 10 V
Vgs (Max):±20V
Input Capacitance (Ciss) (Max) @ Vds:8500 pF @ 20 V
FET Feature:-
Power Dissipation (Max):83W (Ta)
Operating Temperature:-55°C ~ 150°C (TA)
Mounting Type:Surface Mount
Supplier Device Package:8-PQFN (5x6)
Package / Case:8-PowerTDFN
