Overview
The FDB1D7N10CL7 is a high-performance N-Channel MOSFET produced by onsemi. This device is part of the low to medium voltage MOSFET family and is designed to provide high current handling and low on-resistance. It is packaged in a D2PAK (TO-263) package, making it suitable for a variety of power management and switching applications.
Key Specifications
| Parameter | Value |
|---|---|
| VDS (Drain-Source Voltage) | 100 V |
| ID (Continuous Drain Current) | 268 A |
| RDS(ON) (On-Resistance) | 1.7 mΩ |
| VGS (Gate-Source Voltage) | ±20 V |
| PD (Power Dissipation) | Dependent on package and thermal conditions |
| Package | D2PAK (TO-263) |
Key Features
- High current handling capability of up to 268 A.
- Low on-resistance of 1.7 mΩ, reducing power losses.
- Standard gate drive, compatible with a wide range of gate drivers.
- D2PAK (TO-263) package for efficient heat dissipation and compact design.
- Suitable for high-frequency switching applications due to its low gate charge and fast switching times.
Applications
- Power supplies and DC-DC converters.
- Motor control and drive systems.
- High-power switching and amplification.
- Automotive and industrial power management systems.
- Renewable energy systems, such as solar and wind power inverters.
Q & A
- What is the maximum drain-source voltage of the FDB1D7N10CL7 MOSFET? The maximum drain-source voltage is 100 V.
- What is the continuous drain current rating of the FDB1D7N10CL7? The continuous drain current rating is 268 A.
- What is the on-resistance of the FDB1D7N10CL7? The on-resistance is 1.7 mΩ.
- In what package is the FDB1D7N10CL7 available? The FDB1D7N10CL7 is available in a D2PAK (TO-263) package.
- What are some typical applications for the FDB1D7N10CL7? Typical applications include power supplies, motor control systems, high-power switching, and automotive/industrial power management.
- What is the maximum gate-source voltage for the FDB1D7N10CL7? The maximum gate-source voltage is ±20 V.
- Why is the FDB1D7N10CL7 suitable for high-frequency switching applications? It is suitable due to its low gate charge and fast switching times.
- What is the standard lead time for the FDB1D7N10CL7 from onsemi? The standard lead time is 14 weeks.
- Where can I find detailed specifications for the FDB1D7N10CL7? Detailed specifications can be found in the datasheet available on onsemi’s official website and through distributors like DigiKey.
- Is the FDB1D7N10CL7 suitable for renewable energy applications? Yes, it is suitable for renewable energy systems such as solar and wind power inverters.
