NVTA7002NT1G
  • Share:

onsemi NVTA7002NT1G

Manufacturer No:
NVTA7002NT1G
Manufacturer:
onsemi
Package:
Tape & Reel (TR)
Description:
MOSFET N-CH 30V 154MA SC75
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The NVTA7002NT1G is a single N-Channel small signal MOSFET produced by onsemi. This component is designed for applications requiring low gate charge and fast switching capabilities. Although it is no longer in production, it remains a viable option for existing designs and inventory management. The MOSFET is packaged in a SC-75 package, making it suitable for a variety of electronic circuits where space is a concern.

Key Specifications

ParameterValue
Channel TypeN-Channel
Drain to Source Voltage (Vdss)30 V
Continuous Drain Current (Id) @ 25°C154 mA
Maximum Operating Temperature+150°C
Power Dissipation (Pd)300 mW
QualificationAEC-Q100

Key Features

  • Low gate charge for fast switching
  • Gate ESD protection
  • Small signal MOSFET in SC-75 package
  • Enhancement mode operation
  • High maximum operating temperature of +150°C

Applications

The NVTA7002NT1G is suitable for a range of applications including but not limited to:

  • Automotive systems requiring AEC-Q100 qualification
  • Small signal switching circuits
  • Low power electronic devices
  • Industrial control systems

Q & A

  1. What is the maximum drain to source voltage of the NVTA7002NT1G?
    The maximum drain to source voltage is 30 V.
  2. What is the continuous drain current at 25°C?
    The continuous drain current at 25°C is 154 mA.
  3. What is the maximum operating temperature of the NVTA7002NT1G?
    The maximum operating temperature is +150°C.
  4. Is the NVTA7002NT1G still in production?
    No, the NVTA7002NT1G is no longer being manufactured.
  5. What is the package type of the NVTA7002NT1G?
    The package type is SC-75.
  6. What is the power dissipation of the NVTA7002NT1G?
    The power dissipation is 300 mW.
  7. Does the NVTA7002NT1G have gate ESD protection?
    Yes, it has gate ESD protection.
  8. What is the qualification standard for the NVTA7002NT1G?
    The qualification standard is AEC-Q100.
  9. What are some typical applications for the NVTA7002NT1G?
    Typical applications include automotive systems, small signal switching circuits, low power electronic devices, and industrial control systems.
  10. Why is low gate charge important in the NVTA7002NT1G?
    Low gate charge is important for fast switching capabilities in the MOSFET.

Product Attributes

FET Type:N-Channel
Technology:MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):30 V
Current - Continuous Drain (Id) @ 25°C:154mA (Tj)
Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
Rds On (Max) @ Id, Vgs:7Ohm @ 154mA, 4.5V
Vgs(th) (Max) @ Id:1.5V @ 100µA
Gate Charge (Qg) (Max) @ Vgs:-
Vgs (Max):±10V
Input Capacitance (Ciss) (Max) @ Vds:20 pF @ 5 V
FET Feature:-
Power Dissipation (Max):300mW (Tj)
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Supplier Device Package:SC-75, SOT-416
Package / Case:SC-75, SOT-416
