Product Introduction

Overview

The BUK9275-100A,118 is an N-channel TrenchMOS logic level FET produced by Nexperia, which was previously part of NXP Semiconductors. This MOSFET is designed for high-performance applications and has been qualified to the appropriate AEC standard for use in automotive critical applications. However, it is important to note that this product has been discontinued.

Key Specifications

ParameterValue
VDS (Drain-Source Voltage)100 V
ID (Continuous Drain Current)21.7 A
VGS(th) (Threshold Voltage)1 to 2 V
RDS(on) (On-State Resistance)Typically 2.5 mΩ
PackageDPAK (TO-252)
Lead TypeLead Free

Key Features

  • High efficiency due to low on-state resistance (RDS(on)) of typically 2.5 mΩ.
  • Logic level gate drive for easy interface with microcontrollers and other logic circuits.
  • Qualified to AEC-Q101 for automotive applications, ensuring reliability in critical automotive systems.
  • DPAK (TO-252) package for good thermal performance and ease of mounting.

Applications

  • Automotive systems: Suitable for use in critical automotive applications due to its AEC-Q101 qualification.
  • Power management: Ideal for power switching and power management in various electronic systems.
  • Industrial control: Used in industrial control systems where high current and low on-state resistance are required.

Q & A

  1. What is the drain-source voltage (VDS) of the BUK9275-100A,118?
    The drain-source voltage (VDS) is 100 V.
  2. What is the continuous drain current (ID) of this MOSFET?
    The continuous drain current (ID) is 21.7 A.
  3. What is the typical on-state resistance (RDS(on)) of the BUK9275-100A,118?
    The typical on-state resistance (RDS(on)) is 2.5 mΩ.
  4. What package type is used for the BUK9275-100A,118?
    The package type is DPAK (TO-252).
  5. Is the BUK9275-100A,118 lead-free?
    Yes, the BUK9275-100A,118 is lead-free.
  6. What is the threshold voltage (VGS(th)) range for this MOSFET?
    The threshold voltage (VGS(th)) range is 1 to 2 V.
  7. Why was the BUK9275-100A,118 discontinued?
    The specific reason for discontinuation is not provided, but it is noted that the product has been discontinued.
  8. What are some common applications for the BUK9275-100A,118?
    Common applications include automotive systems, power management, and industrial control.
  9. Is the BUK9275-100A,118 suitable for automotive critical applications?
    Yes, it is qualified to the AEC-Q101 standard for automotive critical applications.
  10. Where can I find detailed specifications for the BUK9275-100A,118?
    Detailed specifications can be found on the official Nexperia website, Digi-Key, Mouser Electronics, and other electronic component distributors.

Product Attributes

FET Type:N-Channel
Technology:MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):100 V
Current - Continuous Drain (Id) @ 25°C:21.7A (Tc)
Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
Rds On (Max) @ Id, Vgs:72mOhm @ 10A, 10V
Vgs(th) (Max) @ Id:2V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:-
Vgs (Max):±10V
Input Capacitance (Ciss) (Max) @ Vds:1690 pF @ 25 V
FET Feature:-
Power Dissipation (Max):88W (Tc)
Operating Temperature:-55°C ~ 175°C (TJ)
Mounting Type:Surface Mount
Supplier Device Package:DPAK
Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
