BSS138BKW/DG/B2135
  • Share:

Nexperia USA Inc. BSS138BKW/DG/B2135

Manufacturer No:
BSS138BKW/DG/B2135
Manufacturer:
Nexperia USA Inc.
Package:
Bulk
Description:
SMALL SIGNAL N-CHANNEL MOSFET
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The BSS138BKW,115 is an N-channel logic level enhancement mode field-effect transistor (FET) designed for low voltage applications. It is manufactured by Nexperia USA Inc. and features a compact SOT323 (SC-70) package. This MOSFET is suitable for use in various digital and analog circuits where low power consumption and high switching speed are required.

Key Specifications

Type number Package version Package name Product status Channel type Nr of transistors VDS [max] (V) RDSon [max] @ VGS = 10 V (mΩ) RDSon [max] @ VGS = 4.5 V (mΩ) RDSon [max] @ VGS = 2.5 V (mΩ) Tj [max] (°C) ID [max] (A) QGD [typ] (nC) QG(tot) [typ] @ VGS = 4.5 V (nC) Ptot [max] (W) VGSth [typ] (V) Automotive qualified Ciss [typ] (pF) Coss [typ] (pF)
BSS138BKW SOT323 SC-70 Production N 1 60 1600 2200 6500 150 0.32 0.2 0.6 0.26 1.1 Yes 42 7

Key Features

  • Compact SOT323 (SC-70) package, ideal for space-constrained designs.
  • N-channel logic level enhancement mode FET, suitable for low voltage applications.
  • Low on-resistance (RDSon) at various gate-source voltages (VGS): 1600 mΩ @ VGS = 10 V, 2200 mΩ @ VGS = 4.5 V, and 6500 mΩ @ VGS = 2.5 V.
  • High switching speed and low power consumption, making it suitable for digital and analog circuits.
  • Automotive qualified (AEC-Q101), ensuring reliability in automotive applications.
  • Maximum drain-source voltage (VDS) of 60 V and maximum drain current (ID) of 0.32 A.

Applications

The BSS138BKW,115 is versatile and can be used in a variety of applications, including:

  • Digital and analog circuits requiring low power consumption and high switching speed.
  • Pulse-width modulation (PWM) applications.
  • Automotive systems due to its AEC-Q101 qualification.
  • General-purpose switching in low voltage circuits.

Q & A

  1. Q: What is the maximum drain-source voltage (VDS) of the BSS138BKW,115?

    A: The maximum drain-source voltage (VDS) is 60 V.

  2. Q: Can the BSS138BKW,115 be used for PWM applications?

    A: Yes, the BSS138BKW,115 is suitable for pulse-width modulation (PWM) applications requiring efficient switching at low voltages.

  3. Q: What is the package type of the BSS138BKW,115?

    A: The BSS138BKW,115 comes in a compact SOT323 (SC-70) package.

  4. Q: Is the BSS138BKW,115 automotive qualified?

    A: Yes, the BSS138BKW,115 is automotive qualified (AEC-Q101).

  5. Q: What is the maximum drain current (ID) of the BSS138BKW,115?

    A: The maximum drain current (ID) is 0.32 A.

  6. Q: What are the typical gate-source threshold voltage (VGSth) and on-resistance (RDSon) values?

    A: The typical gate-source threshold voltage (VGSth) is 1.1 V, and the on-resistance (RDSon) values are 1600 mΩ @ VGS = 10 V, 2200 mΩ @ VGS = 4.5 V, and 6500 mΩ @ VGS = 2.5 V.

  7. Q: What is the maximum junction temperature (Tj) of the BSS138BKW,115?

    A: The maximum junction temperature (Tj) is 150°C.

  8. Q: What are the typical input and output capacitances (Ciss and Coss) of the BSS138BKW,115?

    A: The typical input capacitance (Ciss) is 42 pF, and the typical output capacitance (Coss) is 7 pF.

  9. Q: Can I use the BSS138BKW,115 in both digital and analog circuits?

    A: Yes, the BSS138BKW,115 is suitable for use in both digital and analog circuits where low power consumption and high switching speed are required.

  10. Q: Where can I find detailed technical specifications for the BSS138BKW,115?

    A: Detailed technical specifications can be found in the BSS138BKW,115 datasheet.

Product Attributes

FET Type:-
Technology:-
Drain to Source Voltage (Vdss):-
Current - Continuous Drain (Id) @ 25°C:-
Drive Voltage (Max Rds On, Min Rds On):-
Rds On (Max) @ Id, Vgs:-
Vgs(th) (Max) @ Id:-
Gate Charge (Qg) (Max) @ Vgs:-
Vgs (Max):-
Input Capacitance (Ciss) (Max) @ Vds:-
FET Feature:-
Power Dissipation (Max):-
Operating Temperature:-
Mounting Type:-
Supplier Device Package:-
Package / Case:-
0 Remaining View Similar

In Stock

-
314

Please send RFQ , we will respond immediately.
