PMDPB70XPE
  • Share:

NXP USA Inc. PMDPB70XPE

Manufacturer No:
PMDPB70XPE
Manufacturer:
NXP USA Inc.
Package:
Bulk
Description:
NOW NEXPERIA PMDPB70XPE - SMALL
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The PMDPB70XPE,115 is a discrete semiconductor product manufactured by NXP USA Inc. This component is designed to integrate two P-Channel MOSFETs in a single package, making it suitable for various electronic applications that require dual FET functionality.

Key Specifications

ParameterValue
Configuration2 P-Channel (Dual) FETs
Package TypeSSOT6 (SOT363)
Drain-Source Voltage (Vds)-20 V
Gate-Source Voltage (Vgs)-20 V
Continuous Drain Current (Id)-1.5 A
On-State Resistance (Rds(on))Typically 70 mΩ at Vgs = -4.5 V
Threshold Voltage (Vth)Typically -1.5 V
Operating Temperature Range-55°C to 150°C

Key Features

  • Dual P-Channel MOSFETs in a single SSOT6 (SOT363) package, enhancing space efficiency and simplifying board design.
  • Low on-state resistance (Rds(on)) of typically 70 mΩ at Vgs = -4.5 V, reducing power losses.
  • High continuous drain current (Id) of -1.5 A, suitable for applications requiring moderate to high current handling.
  • Wide operating temperature range from -55°C to 150°C, making it versatile for various environmental conditions.

Applications

The PMDPB70XPE,115 is suitable for a variety of applications, including but not limited to:

  • Power management and switching circuits.
  • Audio and video switching.
  • Load switching and control.
  • General-purpose analog and digital circuits.

Q & A

  1. What is the configuration of the PMDPB70XPE,115? The PMDPB70XPE,115 features 2 P-Channel (Dual) FETs.
  2. What is the package type of the PMDPB70XPE,115? The package type is SSOT6 (SOT363).
  3. What is the maximum drain-source voltage (Vds) for the PMDPB70XPE,115? The maximum drain-source voltage is -20 V.
  4. What is the typical on-state resistance (Rds(on)) of the PMDPB70XPE,115? The typical on-state resistance is 70 mΩ at Vgs = -4.5 V.
  5. What is the continuous drain current (Id) of the PMDPB70XPE,115? The continuous drain current is -1.5 A.
  6. What is the operating temperature range of the PMDPB70XPE,115? The operating temperature range is from -55°C to 150°C.
  7. What are some common applications for the PMDPB70XPE,115? Common applications include power management, audio and video switching, load switching, and general-purpose analog and digital circuits.
  8. Where can I find detailed specifications for the PMDPB70XPE,115? Detailed specifications can be found on official NXP websites, Digi-Key, Mouser Electronics, and other authorized distributors.
  9. What are the benefits of using a dual MOSFET package like the PMDPB70XPE,115? Benefits include space efficiency, simplified board design, and reduced component count.
  10. Is the PMDPB70XPE,115 suitable for high-temperature environments? Yes, it operates within a temperature range of -55°C to 150°C.
