Overview
The 2N7002BKMB is a 60 V, single N-channel Trench MOSFET produced by Nexperia. It is packaged in a leadless ultra small DFN1006B-3 (SOT883B) Surface-Mounted Device (SMD) plastic package. This MOSFET utilizes Trench MOSFET technology, offering enhanced performance and reliability.
Key Specifications
| Parameter | Value |
|---|---|
| Type number | 2N7002BKMB |
| Package version | SOT883B |
| Package name | DFN1006B-3 |
| Product status | End of life |
| Channel type | N |
| Nr of transistors | 1 |
| V DS [max] (V) | 60 |
| V GS [max] (V) | 20 |
| R DSon [max] @ V GS = 10 V (mΩ) | 1600 |
| R DSon [max] @ V GS = 5 V (mΩ) | 2000 |
| T j [max] (°C) | 150 |
| I D [max] (A) | 0.45 |
| Q GD [typ] (nC) | 0.1 |
| Q G(tot) [typ] @ V GS = 4.5 V (nC) | 0.5 |
| P tot [max] (W) | 0.36 |
| V GSth [typ] (V) | 1.6 |
| Automotive qualified | No |
| C iss [typ] (pF) | 33 |
| C oss [typ] (pF) | 7 |
Key Features
- Very fast switching
- Trench MOSFET technology
- ESD protection up to 2 kV
- Logic-level compatible
- Ultra thin package profile with 0.37 mm height
Applications
- Relay driver
- High-speed line driver
- Low-side load switch
- Switching circuits
Q & A
- What is the maximum drain-source voltage (V DS) of the 2N7002BKMB?
The maximum drain-source voltage (V DS) is 60 V. - What is the maximum gate-source voltage (V GS) of the 2N7002BKMB?
The maximum gate-source voltage (V GS) is 20 V. - What is the typical on-resistance (R DSon) at V GS = 10 V?
The typical on-resistance (R DSon) at V GS = 10 V is 1600 mΩ. - Does the 2N7002BKMB have ESD protection?
Yes, it has ESD protection up to 2 kV. - What is the package type of the 2N7002BKMB?
The package type is DFN1006B-3 (SOT883B). - What are the typical applications of the 2N7002BKMB?
Typical applications include relay drivers, high-speed line drivers, low-side load switches, and switching circuits. - Is the 2N7002BKMB automotive qualified?
No, it is not automotive qualified. - What is the maximum junction temperature (T j) of the 2N7002BKMB?
The maximum junction temperature (T j) is 150 °C. - What is the maximum continuous drain current (I D) of the 2N7002BKMB?
The maximum continuous drain current (I D) is 0.45 A. - What is the typical gate-drain charge (Q GD) of the 2N7002BKMB?
The typical gate-drain charge (Q GD) is 0.1 nC.
