Product Introduction

Overview

The NX7002BKM315 is a small signal N-channel Trench MOSFET produced by Nexperia (formerly part of NXP USA Inc.). This component is designed for use in a variety of applications requiring high efficiency and reliability. It features a compact SOT23 (TO-236AB) package, making it suitable for space-constrained designs.

Key Specifications

Parameter Value Unit
Type Number NX7002BKM315 -
Package SOT23 (TO-236AB) -
Channel Type N-channel -
Number of Transistors 1 -
VDS (max) 60 V
VGS (max) 20 V
RDSon (max) @ VGS = 10 V 2800 mΩ
RDSon (max) @ VGS = 5 V 3200 mΩ
VESD (HBM) > 2 kV kV
Tj (max) 150 °C
ID (max) 0.19 A
Ptot (max) 1.33 W
VGSth (typ) 1.1 - 2.1 V

Key Features

  • Logic-level compatible: The MOSFET can be driven directly by logic gates.
  • Very fast switching: Ideal for high-speed applications.
  • Trench MOSFET technology: Provides low on-resistance and high efficiency.
  • ElectroStatic Discharge (ESD) protection: > 2 kV HBM, ensuring robustness against static discharge.
  • Compact SOT23 package: Suitable for space-constrained designs.

Applications

  • Relay driver: Used to control relays in various electronic systems.
  • High-speed line driver: Suitable for high-speed signal transmission applications.
  • Low-side load switch: Used in power management circuits to control load switching.
  • Switching circuits: General-purpose switching applications in automotive, industrial, and consumer electronics.

Q & A

  1. What is the maximum drain-source voltage (VDS) of the NX7002BKM315?

    The maximum drain-source voltage (VDS) is 60 V.

  2. What is the package type of the NX7002BKM315?

    The package type is SOT23 (TO-236AB).

  3. What is the maximum gate-source voltage (VGS)?

    The maximum gate-source voltage (VGS) is 20 V.

  4. What is the typical threshold voltage (VGSth) range?

    The typical threshold voltage (VGSth) range is 1.1 to 2.1 V.

  5. Does the NX7002BKM315 have ESD protection?

    Yes, it has ESD protection greater than 2 kV HBM.

  6. What is the maximum junction temperature (Tj)?

    The maximum junction temperature (Tj) is 150°C.

  7. What is the maximum drain current (ID)?

    The maximum drain current (ID) is 0.19 A.

  8. Is the NX7002BKM315 RoHS compliant?

    Yes, the NX7002BKM315 is RoHS compliant.

  9. What are some common applications of the NX7002BKM315?

    Common applications include relay drivers, high-speed line drivers, low-side load switches, and general switching circuits.

  10. How can I obtain the datasheet for the NX7002BKM315?

    You can download the datasheet from the official Nexperia website or through authorized distributors.
