NX7002BKSX
  • Share:

Nexperia USA Inc. NX7002BKSX

Manufacturer No:
NX7002BKSX
Manufacturer:
Nexperia USA Inc.
Package:
Tape & Reel (TR)
Description:
MOSFET N-CH 60V 270MA 6TSSOP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The NX7002BKSX is a dual N-channel Trench MOSFET produced by Nexperia USA Inc. This component is designed to offer high performance and reliability in a compact package. It features logic-level gate technology, making it compatible with a wide range of applications. The MOSFET is known for its enhanced power dissipation, low on-resistance, and high-speed switching capabilities, making it suitable for demanding environments.

Key Specifications

ParameterValue
Drain to Source Voltage (Vds)60 V
Continuous Drain Current (Id)240 mA
On-Resistance (Rds(on))Low on-resistance
Package Type6-TSSOP, SC-88, SOT-363
Operational Temperature Range-55°C to 150°C
Power Dissipation320 mW
ESD Protection> 2 kV HBM
ComplianceLead free and RoHS compliant

Key Features

  • Logic-level gate technology for compatibility with various logic levels.
  • Enhanced power dissipation for efficient heat management.
  • Low on-resistance for minimal power loss.
  • High-speed switching for fast operation.
  • Dual N-Channel configuration for versatile use.
  • Compact form factor in 6-TSSOP, SC-88, SOT-363 packages.
  • Surface mount type with Tape & Reel (TR) for automated assembly.
  • ESD protection greater than 2 kV HBM.
  • Lead free and RoHS compliant.

Applications

The NX7002BKSX is ideal for a variety of applications, including:

  • Power management in consumer electronics.
  • Telecommunications systems requiring high reliability and efficiency.
  • Automotive circuits where robust performance is essential.
  • Space-constrained applications where compact form factors are necessary.

Q & A

  1. What is the drain to source voltage rating of the NX7002BKSX?
    The drain to source voltage rating is 60 V.
  2. What is the continuous drain current of the NX7002BKSX?
    The continuous drain current is 240 mA.
  3. What package types are available for the NX7002BKSX?
    The component is available in 6-TSSOP, SC-88, and SOT-363 packages.
  4. What is the operational temperature range of the NX7002BKSX?
    The operational temperature range is from -55°C to 150°C.
  5. Is the NX7002BKSX RoHS compliant?
    Yes, the NX7002BKSX is lead free and RoHS compliant.
  6. What is the ESD protection level of the NX7002BKSX?
    The ESD protection level is greater than 2 kV HBM.
  7. What are the key features of the NX7002BKSX?
    The key features include logic-level gate technology, enhanced power dissipation, low on-resistance, high-speed switching, and a dual N-Channel configuration.
  8. In which applications is the NX7002BKSX commonly used?
    The NX7002BKSX is commonly used in power management, telecommunications systems, automotive circuits, and space-constrained applications.
  9. What is the power dissipation of the NX7002BKSX?
    The power dissipation is 320 mW.
  10. Is the NX7002BKSX suitable for automated assembly?
    Yes, it is available in Tape & Reel (TR) for automated assembly.

Product Attributes

FET Type:N-Channel
Technology:MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):60 V
Current - Continuous Drain (Id) @ 25°C:270mA (Ta)
Drive Voltage (Max Rds On, Min Rds On):5V, 10V
Rds On (Max) @ Id, Vgs:2.8Ohm @ 200mA, 10V
Vgs(th) (Max) @ Id:2.1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:1 nC @ 10 V
Vgs (Max):±20V
Input Capacitance (Ciss) (Max) @ Vds:23.6 pF @ 10 V
FET Feature:-
Power Dissipation (Max):310mW (Ta), 1.67W (Tc)
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Supplier Device Package:6-TSSOP
Package / Case:6-TSSOP, SC-88, SOT-363
0 Remaining View Similar

In Stock

$0.41
1,963

Please send RFQ , we will respond immediately.

Similar Products

Part Number NX7002BKSX NX7002BKWX
Manufacturer Nexperia USA Inc. Nexperia USA Inc.
Product Status Active Active
FET Type N-Channel N-Channel
Technology MOSFET (Metal Oxide) MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 60 V 60 V
Current - Continuous Drain (Id) @ 25°C 270mA (Ta) 270mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) 5V, 10V 5V, 10V
Rds On (Max) @ Id, Vgs 2.8Ohm @ 200mA, 10V 2.8Ohm @ 200mA, 10V
Vgs(th) (Max) @ Id 2.1V @ 250µA 2.1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 1 nC @ 10 V 1 nC @ 10 V
Vgs (Max) ±20V ±20V
Input Capacitance (Ciss) (Max) @ Vds 23.6 pF @ 10 V 23.6 pF @ 10 V
FET Feature - -
Power Dissipation (Max) 310mW (Ta), 1.67W (Tc) 310mW (Ta), 1.67W (Tc)
Operating Temperature -55°C ~ 150°C (TJ) -55°C ~ 150°C (TJ)
Mounting Type Surface Mount Surface Mount
Supplier Device Package 6-TSSOP SOT-323
Package / Case 6-TSSOP, SC-88, SOT-363 SC-70, SOT-323
