BUK9832-55A/CUX
  • Share:

Nexperia USA Inc. BUK9832-55A/CUX

Manufacturer No:
BUK9832-55A/CUX
Manufacturer:
Nexperia USA Inc.
Package:
Tape & Reel (TR)
Description:
MOSFET N-CH 55V 12A SOT223
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The Nexperia BUK9832-55A/CUX is a high-performance N-Channel TrenchMOS logic level FET, part of the TrenchMOS series. This MOSFET is designed to offer low on-state resistance and high efficiency, making it suitable for a variety of applications, particularly in automotive and industrial sectors. The device is packaged in a SOT-223 (TO-261-4, SC-73) case, which is a surface mount type, facilitating easy integration into modern electronic designs.

Key Specifications

Attribute Value
FET Type N-Channel
No of Channels 1
Drain-to-Source Voltage (Vdss) 55V
Drain-Source On Resistance-Max (Rds(on)) 32mΩ
Rated Power Dissipation (Pd) 8W
Gate-Source Voltage-Max (Vgss) 10V
Drain Current (Id) 12A
Turn-on Delay Time 14ns
Turn-off Delay Time 64ns
Rise Time 125ns
Fall Time 68ns
Operating Temperature Range -55°C to +150°C
Gate Source Threshold Voltage 2V
Technology Silicon (Si)
Height - Max 1.8mm
Length 6.7mm
Input Capacitance 1195pF
Package Style SOT-223 (TO-261-4, SC-73)
Mounting Method Surface Mount

Key Features

  • Low On-State Resistance: The BUK9832-55A/CUX features a low Rds(on) of 32mΩ, which enhances the overall efficiency of the system.
  • High Drain Current: With a continuous drain current of 12A, this MOSFET is capable of handling high current applications.
  • Wide Operating Temperature Range: The device operates over a temperature range of -55°C to +150°C, making it suitable for harsh environments.
  • Automotive Qualification: Qualified to AEC-Q101 standards, ensuring reliability and performance in automotive applications.
  • RoHS Compliance: The component is RoHS compliant, ensuring environmental sustainability.
  • Fast Switching Times: The MOSFET has fast turn-on and turn-off times, contributing to efficient switching operations.

Applications

  • Automotive Systems: Suitable for use in various automotive applications such as power steering, braking systems, and engine management.
  • Industrial Power Supplies: Can be used in industrial power supplies, motor control, and DC-DC converters.
  • Consumer Electronics: Applicable in consumer electronics for power management and switching circuits.
  • Renewable Energy Systems: Used in solar and wind power systems for efficient power conversion.

Q & A

  1. What is the maximum drain-to-source voltage of the BUK9832-55A/CUX?

    The maximum drain-to-source voltage (Vdss) is 55V.

  2. What is the on-state resistance (Rds(on)) of this MOSFET?

    The on-state resistance (Rds(on)) is 32mΩ.

  3. What is the continuous drain current (Id) of the BUK9832-55A/CUX?

    The continuous drain current (Id) is 12A.

  4. What is the operating temperature range of this device?

    The operating temperature range is -55°C to +150°C.

  5. Is the BUK9832-55A/CUX RoHS compliant?

    Yes, the component is RoHS compliant.

  6. What is the package style of the BUK9832-55A/CUX?

    The package style is SOT-223 (TO-261-4, SC-73).

  7. What is the mounting method for this MOSFET?

    The mounting method is surface mount.

  8. Is the BUK9832-55A/CUX qualified for automotive use?

    Yes, it is qualified to AEC-Q101 standards.

  9. What are the typical applications of the BUK9832-55A/CUX?

    Typical applications include automotive systems, industrial power supplies, consumer electronics, and renewable energy systems.

  10. What is the gate-source threshold voltage of this MOSFET?

    The gate-source threshold voltage is 2V.

Product Attributes

FET Type:N-Channel
Technology:MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):55 V
Current - Continuous Drain (Id) @ 25°C:12A (Tc)
Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
Rds On (Max) @ Id, Vgs:29mOhm @ 8A, 10V
Vgs(th) (Max) @ Id:2V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:-
Vgs (Max):±10V
Input Capacitance (Ciss) (Max) @ Vds:1594 pF @ 25 V
FET Feature:-
Power Dissipation (Max):8W (Tc)
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Supplier Device Package:SOT-223
Package / Case:TO-261-4, TO-261AA
0 Remaining View Similar

In Stock

$0.94
359

Please send RFQ , we will respond immediately.
