NSS20500UW3T2G
  • Share:

onsemi NSS20500UW3T2G

Manufacturer No:
NSS20500UW3T2G
Manufacturer:
onsemi
Package:
Tape & Reel (TR)
Description:
TRANS PNP 20V 5A 3WDFN
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The NSS20500UW3T2G is a high-performance PNP bipolar junction transistor (BJT) manufactured by onsemi. This transistor is designed for low voltage drop and high current handling, making it suitable for a variety of power management and switching applications. It features a compact WDFN3 (2x2) surface mount package, which is lead-free and RoHS compliant.

Key Specifications

ParameterValue
Voltage Rating (VCE)20 V
Collector Current (IC)7.0 A
Saturation Voltage (VCE(sat))Low VCE(sat)
Power Dissipation (PD)875 mW
Package TypeWDFN3 (2x2)
Frequency100 MHz
Operating Temperature Range-55°C to 150°C

Key Features

  • Low VCE(sat) for reduced power losses
  • High collector current capability of up to 7.0 A
  • Compact WDFN3 (2x2) surface mount package
  • Lead-free and RoHS compliant
  • High frequency operation up to 100 MHz

Applications

  • Power management and switching circuits
  • Automotive systems
  • Industrial control systems
  • Consumer electronics
  • Audio and video equipment

Q & A

  1. What is the voltage rating of the NSS20500UW3T2G transistor?
    The voltage rating (VCE) of the NSS20500UW3T2G transistor is 20 V.
  2. What is the maximum collector current of the NSS20500UW3T2G?
    The maximum collector current (IC) of the NSS20500UW3T2G is 7.0 A.
  3. What is the package type of the NSS20500UW3T2G?
    The NSS20500UW3T2G comes in a WDFN3 (2x2) surface mount package.
  4. Is the NSS20500UW3T2G RoHS compliant?
    Yes, the NSS20500UW3T2G is lead-free and RoHS compliant.
  5. What is the power dissipation of the NSS20500UW3T2G?
    The power dissipation (PD) of the NSS20500UW3T2G is 875 mW.
  6. What is the frequency range of the NSS20500UW3T2G?
    The NSS20500UW3T2G operates up to 100 MHz.
  7. What are some common applications of the NSS20500UW3T2G?
    The NSS20500UW3T2G is commonly used in power management and switching circuits, automotive systems, industrial control systems, consumer electronics, and audio and video equipment.
  8. What is the operating temperature range of the NSS20500UW3T2G?
    The operating temperature range of the NSS20500UW3T2G is -55°C to 150°C.
  9. Is the NSS20500UW3T2G suitable for high-current applications?
    Yes, the NSS20500UW3T2G is suitable for high-current applications due to its high collector current capability.
  10. Where can I find detailed specifications for the NSS20500UW3T2G?
    Detailed specifications for the NSS20500UW3T2G can be found in the datasheet available on the onsemi website or through distributors like Mouser and Digi-Key.

Product Attributes

Transistor Type:PNP
Current - Collector (Ic) (Max):5 A
Voltage - Collector Emitter Breakdown (Max):20 V
Vce Saturation (Max) @ Ib, Ic:260mV @ 400mA, 4A
Current - Collector Cutoff (Max):100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce:200 @ 2A, 2V
Power - Max:875 mW
Frequency - Transition:100MHz
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Package / Case:3-WDFN Exposed Pad
Supplier Device Package:3-WDFN (2x2)
0 Remaining View Similar

In Stock

$0.58
964

Please send RFQ , we will respond immediately.

Same Series
NSS20500UW3TBG
NSS20500UW3TBG
TRANS PNP 20V 5A 3WDFN

Similar Products

Part Number NSS20500UW3T2G NSS20501UW3T2G NSS40500UW3T2G
Manufacturer onsemi onsemi onsemi
Product Status Active Active Active
Transistor Type PNP NPN PNP
Current - Collector (Ic) (Max) 5 A 5 A 5 A
Voltage - Collector Emitter Breakdown (Max) 20 V 20 V 40 V
Vce Saturation (Max) @ Ib, Ic 260mV @ 400mA, 4A 125mV @ 400mA, 4A 260mV @ 400mA, 4A
Current - Collector Cutoff (Max) 100nA (ICBO) 100nA (ICBO) 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 2A, 2V 200 @ 2A, 2V 180 @ 2A, 2V
Power - Max 875 mW 875 mW 875 mW
Frequency - Transition 100MHz 150MHz 100MHz
Operating Temperature -55°C ~ 150°C (TJ) -55°C ~ 150°C (TJ) -55°C ~ 150°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount
Package / Case 3-WDFN Exposed Pad 3-WDFN Exposed Pad 3-WDFN Exposed Pad
Supplier Device Package 3-WDFN (2x2) 3-WDFN (2x2) 3-WDFN (2x2)
