Overview
The ECH8502-TL-H is a bipolar transistor array produced by onsemi, designed for various driver and gate drive applications. This component is part of the general-purpose and low VCE(sat) transistor family, offering high performance and reliability. Although the product is no longer in production, it remains available from various distributors and inventory holders.
Key Specifications
| Parameter | Value |
|---|---|
| Collector-Base Voltage (Vcb) | -50V |
| Collector-Emitter Voltage (Vce) | -50V |
| Emitter-Base Voltage (Veb) | -5V |
| Collector Current (Ic) | -30A |
| Saturation Voltage (Vce(sat)) | Low Vce(sat) |
| Packaging | Through-Hole |
| Weight | 0.02 g |
| Dimensions | Refer to datasheet for detailed dimensions |
| Environmental Compliance | Pb Free and Halogen Free |
Key Features
- Low VCE(sat) for efficient operation
- High collector current capability of -30A
- Complementary dual configuration for balanced performance
- Pb Free and Halogen Free, ensuring environmental compliance
- Through-Hole packaging for easy integration into various circuits
Applications
The ECH8502-TL-H is suitable for a variety of applications, including:
- Driver circuits for high-current devices
- Gate drive circuits for power electronics
- General-purpose switching and amplification
- Automotive and industrial control systems
