Overview
The NRVTSAF360T3G is a trench-based Schottky rectifier produced by ON Semiconductor. This component is designed to offer high performance and reliability in various power management applications. It is known for its low forward voltage drop, high current handling, and fast switching times, making it suitable for a wide range of electronic systems.
Key Specifications
| Parameter | Value |
|---|---|
| Voltage Rating (V_RRM) | 60 V |
| Maximum Average Forward Current (I_F(AV)) | 3 A |
| Maximum Peak Forward Surge Current (I_FSM) | 75 A |
| Forward Voltage Drop (V_F) | |
| Reverse Recovery Time (t_rr) | |
| Operating Junction Temperature (T_J) | -55°C to 150°C |
| Package | SMB (DO-214AA) |
Key Features
- Low forward voltage drop, typically 0.36 V at 3 A, reducing power losses.
- High current handling capability with a maximum average forward current of 3 A.
- Fast switching times with a reverse recovery time of typically 25 ns.
- Trench-based Schottky technology for improved efficiency and reliability.
- Compact SMB (DO-214AA) package for space-saving designs.
Applications
- Power supplies and DC-DC converters.
- Motor control and drive systems.
- Switch-mode power supplies.
- High-frequency switching applications.
- Automotive and industrial power management systems.
Q & A
- What is the voltage rating of the NRVTSAF360T3G?
The voltage rating (V_RRM) of the NRVTSAF360T3G is 60 V. - What is the maximum average forward current of the NRVTSAF360T3G?
The maximum average forward current (I_F(AV)) is 3 A. - What is the typical forward voltage drop of the NRVTSAF360T3G?
The typical forward voltage drop (V_F) is 0.36 V at 3 A. - What is the reverse recovery time of the NRVTSAF360T3G?
The reverse recovery time (t_rr) is typically 25 ns. - What is the operating junction temperature range of the NRVTSAF360T3G?
The operating junction temperature (T_J) range is -55°C to 150°C. - What package type is the NRVTSAF360T3G available in?
The NRVTSAF360T3G is available in the SMB (DO-214AA) package. - What are some common applications of the NRVTSAF360T3G?
Common applications include power supplies, DC-DC converters, motor control systems, switch-mode power supplies, and automotive and industrial power management systems. - Why is the trench-based Schottky technology important in the NRVTSAF360T3G?
The trench-based Schottky technology improves efficiency and reliability by reducing power losses and enhancing switching performance. - Can the NRVTSAF360T3G be used in high-frequency switching applications?
Yes, the NRVTSAF360T3G is suitable for high-frequency switching applications due to its fast switching times. - Where can I find detailed specifications and datasheets for the NRVTSAF360T3G?
Detailed specifications and datasheets can be found on the ON Semiconductor website or through distributors like Digi-Key and Mouser Electronics.
