PMBT2907AMBYL
  • Share:

Nexperia USA Inc. PMBT2907AMBYL

Manufacturer No:
PMBT2907AMBYL
Manufacturer:
Nexperia USA Inc.
Package:
Tape & Reel (TR)
Description:
PMBT2907AMB/SOT883/XQFN3
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The PMBT2907AMBYL is a PNP switching transistor produced by Nexperia USA Inc. This transistor is part of Nexperia’s extensive portfolio of bipolar transistors and is designed for general-purpose switching and linear amplification applications. It is housed in a small SOT23 (TO-236AB) Surface-Mounted Device (SMD) plastic package, making it suitable for space-constrained designs. The PMBT2907AMBYL is AEC-Q101 qualified, ensuring its reliability and performance in automotive and other demanding environments.

Key Specifications

Parameter Conditions Min Typ Max Unit
VCEO (Collector-Emitter Voltage) Open base - - -40 V
IC (Collector Current) - - - -600 mA
hFE (DC Current Gain) VCE = -10 V; IC = -150 mA; Tamb = 25 °C 100 - 300 -
fT (Transition Frequency) VCE = -20 V; IC = -50 mA; f = 100 MHz; Tamb = 25 °C 200 - - MHz
toff (Turn-off Time) - - - 365 ns
Ptot (Total Power Dissipation) - - - 250 mW

Key Features

  • Single General-Purpose Switching Transistor: Suitable for a wide range of switching and linear amplification applications.
  • AEC-Q101 Qualified: Ensures reliability and performance in automotive and other demanding environments.
  • Small SOT23 Package: Compact SOT23 (TO-236AB) Surface-Mounted Device (SMD) plastic package, ideal for space-constrained designs.
  • High Current Gain: DC current gain (hFE) ranges from 100 to 300, ensuring reliable operation.
  • High Transition Frequency: fT of 200 MHz, suitable for high-frequency applications.

Applications

  • Automotive Electronics: AEC-Q101 qualification makes it suitable for various automotive applications, including power management and signal switching.
  • Industrial Control: Used in industrial control systems for switching and amplification tasks.
  • Consumer Electronics: Suitable for use in consumer electronics such as audio amplifiers and power supplies.
  • Power Management: Can be used in power management circuits for efficient switching and amplification.

Q & A

  1. What is the maximum collector-emitter voltage (VCEO) of the PMBT2907AMBYL?

    The maximum collector-emitter voltage (VCEO) is -40 V.

  2. What is the maximum collector current (IC) of the PMBT2907AMBYL?

    The maximum collector current (IC) is -600 mA.

  3. What is the DC current gain (hFE) of the PMBT2907AMBYL?

    The DC current gain (hFE) ranges from 100 to 300.

  4. What is the transition frequency (fT) of the PMBT2907AMBYL?

    The transition frequency (fT) is 200 MHz.

  5. What package type is the PMBT2907AMBYL available in?

    The PMBT2907AMBYL is available in a SOT23 (TO-236AB) Surface-Mounted Device (SMD) plastic package.

  6. Is the PMBT2907AMBYL AEC-Q101 qualified?

    Yes, the PMBT2907AMBYL is AEC-Q101 qualified, ensuring its reliability in automotive and other demanding environments.

  7. What are the typical applications of the PMBT2907AMBYL?

    The PMBT2907AMBYL is typically used in automotive electronics, industrial control systems, consumer electronics, and power management circuits.

  8. What is the total power dissipation (Ptot) of the PMBT2907AMBYL?

    The total power dissipation (Ptot) is 250 mW).

  9. What is the turn-off time (toff) of the PMBT2907AMBYL?

    The turn-off time (toff) is 365 ns).

  10. Can the PMBT2907AMBYL be used for high-frequency applications?

    Yes, with a transition frequency (fT) of 200 MHz, it is suitable for high-frequency applications).

  11. How can I obtain the PMBT2907AMBYL from Nexperia?

    You can order the PMBT2907AMBYL through Nexperia’s sales organization or from authorized distributors like Digi-Key and Mouser).

Product Attributes

Transistor Type:PNP
Current - Collector (Ic) (Max):600 mA
Voltage - Collector Emitter Breakdown (Max):60 V
Vce Saturation (Max) @ Ib, Ic:1.6V @ 50mA, 500mA
Current - Collector Cutoff (Max):10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 150mA, 10V
Power - Max:250 mW
Frequency - Transition:210MHz
Operating Temperature:150°C (TJ)
Mounting Type:Surface Mount
Package / Case:3-XFDFN
Supplier Device Package:DFN1006B-3
0 Remaining View Similar

In Stock

$0.04
12,989

Please send RFQ , we will respond immediately.
