2PC4617RMB,315
  • Share:

Nexperia USA Inc. 2PC4617RMB,315

Manufacturer No:
2PC4617RMB,315
Manufacturer:
Nexperia USA Inc.
Package:
Bulk
Description:
NEXPERIA 2PC4617RMB - SMALL SIGN
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The 2PC4617RMB,315 is a bipolar junction transistor (BJT) produced by Nexperia USA Inc. This NPN transistor is designed for general-purpose applications and is characterized by its high performance and reliability. It features a surface mount package, specifically the DFN1006B-3, making it suitable for a wide range of electronic circuits.

Key Specifications

ParameterValue
TypeNPN Bipolar Junction Transistor
Collector-Emitter Voltage (Vce)50 V
Collector Current (Ic)100 mA
Emitter-Base Voltage (Veb)5 V
Collector-Emitter Saturation Voltage (Vce(sat))200 mV
Power Dissipation (Pd)250 mW
Gain Bandwidth Product (fT)100 MHz
PackageDFN1006B-3 (Surface Mount)
RoHS StatusLead Free / RoHS Compliant

Key Features

  • High-frequency operation with a gain bandwidth product of 100 MHz
  • Low collector-emitter saturation voltage of 200 mV
  • Compact surface mount DFN1006B-3 package
  • RoHS compliant and lead-free
  • Automotive qualified (AEC-Q100/Q101) for reliability in harsh environments

Applications

The 2PC4617RMB,315 is versatile and can be used in a variety of applications, including:

  • General-purpose switching and amplification
  • Automotive systems due to its AEC-Q100/Q101 qualification
  • Audio and signal processing circuits
  • Power management and control circuits

Q & A

  1. What is the collector-emitter voltage rating of the 2PC4617RMB,315?
    The collector-emitter voltage rating is 50 V.
  2. What is the maximum collector current for this transistor?
    The maximum collector current is 100 mA.
  3. What is the package type of the 2PC4617RMB,315?
    The package type is DFN1006B-3 (surface mount).
  4. Is the 2PC4617RMB,315 RoHS compliant?
    Yes, it is lead-free and RoHS compliant.
  5. What is the gain bandwidth product (fT) of this transistor?
    The gain bandwidth product is 100 MHz.
  6. What are some common applications for the 2PC4617RMB,315?
    It is used in general-purpose switching and amplification, automotive systems, audio and signal processing circuits, and power management and control circuits.
  7. Is the 2PC4617RMB,315 suitable for automotive applications?
    Yes, it is AEC-Q100/Q101 qualified, making it suitable for automotive applications.
  8. What is the emitter-base voltage rating of the 2PC4617RMB,315?
    The emitter-base voltage rating is 5 V.
  9. What is the collector-emitter saturation voltage (Vce(sat)) of this transistor?
    The collector-emitter saturation voltage is 200 mV.
  10. What is the power dissipation (Pd) of the 2PC4617RMB,315?
    The power dissipation is 250 mW.

Product Attributes

Transistor Type:NPN
Current - Collector (Ic) (Max):100 mA
Voltage - Collector Emitter Breakdown (Max):50 V
Vce Saturation (Max) @ Ib, Ic:200mV @ 5mA, 50mA
Current - Collector Cutoff (Max):100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce:180 @ 1mA, 6V
Power - Max:250 mW
Frequency - Transition:100MHz
Operating Temperature:150°C (TJ)
Mounting Type:Surface Mount
Package / Case:3-XFDFN
Supplier Device Package:DFN1006B-3
