NSS40601CF8T1G
  • Share:

onsemi NSS40601CF8T1G

Manufacturer No:
NSS40601CF8T1G
Manufacturer:
onsemi
Package:
Tape & Reel (TR)
Description:
TRANS NPN 40V 6A CHIPFET
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The NSS40601CF8T1G is a high-performance NPN transistor designed and manufactured by onsemi. This transistor is optimized for low voltage, high-speed switching applications where efficient energy control is crucial. It is part of onsemi's portfolio of power transistors known for their reliability and performance in various electronic systems.

Key Specifications

Parameter Value
Collector-Base Voltage (VCB) 40 V
Collector-Emitter Voltage (VCE) 40 V
Emitter-Base Voltage (VEB) 5 V
Collector Current (IC) 8.0 A
Base Current (IB) 1.6 A
Collector-Emitter Saturation Voltage (VCE(sat)) 0.2 V (Typical at IC = 4 A, IB = 0.4 A)
Power Dissipation (PD) 20 W
Operating Junction Temperature (TJ) -55°C to 150°C

Key Features

  • Low VCE(sat): Ensures minimal voltage drop during saturation, enhancing efficiency in switching applications.
  • High Collector Current: Supports up to 8.0 A, making it suitable for high-current applications.
  • High-Speed Switching: Designed for fast switching times, ideal for applications requiring rapid on/off cycles.
  • Reliability: Built with robust materials and design to ensure long-term reliability and performance.

Applications

  • DC-DC Converters: Ideal for use in high-efficiency DC-DC converters due to its low VCE(sat) and high current handling.
  • Power Management Systems: Suitable for various power management systems requiring efficient and reliable switching.
  • Automotive Systems: Can be used in automotive applications where high current and low voltage drop are necessary.
  • Industrial Control Systems: Applicable in industrial control systems that demand high reliability and efficiency.

Q & A

  1. What is the maximum collector current of the NSS40601CF8T1G transistor?

    The maximum collector current is 8.0 A.

  2. What is the typical collector-emitter saturation voltage (VCE(sat)) of the NSS40601CF8T1G?

    The typical VCE(sat) is 0.2 V at IC = 4 A and IB = 0.4 A.

  3. What are the operating junction temperature limits for the NSS40601CF8T1G?

    The operating junction temperature range is -55°C to 150°C.

  4. Is the NSS40601CF8T1G suitable for high-speed switching applications?

    Yes, it is designed for high-speed switching applications.

  5. What is the maximum power dissipation (PD) of the NSS40601CF8T1G?

    The maximum power dissipation is 20 W.

  6. Has the NSS40601CF8T1G been discontinued?

    Yes, onsemi has announced the discontinuance of this product, with a final lifetime purchase order period and delivery limitations.

  7. What are some common applications for the NSS40601CF8T1G transistor?

    Common applications include DC-DC converters, power management systems, automotive systems, and industrial control systems.

  8. What is the collector-base voltage (VCB) rating of the NSS40601CF8T1G?

    The collector-base voltage rating is 40 V.

  9. How can I find a replacement for the NSS40601CF8T1G if it is discontinued?

    onsemi recommends contacting their customer service or checking with partnered suppliers like Rochester Electronics and Flip Electronics for remaining inventory or suggested replacement devices.

  10. What is the emitter-base voltage (VEB) rating of the NSS40601CF8T1G?

    The emitter-base voltage rating is 5 V.

Product Attributes

Transistor Type:NPN
Current - Collector (Ic) (Max):6 A
Voltage - Collector Emitter Breakdown (Max):40 V
Vce Saturation (Max) @ Ib, Ic:135mV @ 400mA, 4A
Current - Collector Cutoff (Max):100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce:200 @ 1A, 2V
Power - Max:830 mW
Frequency - Transition:140MHz
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Surface Mount
Package / Case:8-SMD, Flat Lead
Supplier Device Package:ChipFET™
0 Remaining View Similar

In Stock

$0.94
943

Please send RFQ , we will respond immediately.

Similar Products

Part Number NSS40601CF8T1G NSS20601CF8T1G NSS40600CF8T1G
Manufacturer onsemi onsemi onsemi
Product Status Active Active Active
Transistor Type NPN NPN PNP
Current - Collector (Ic) (Max) 6 A 6 A 6 A
Voltage - Collector Emitter Breakdown (Max) 40 V 20 V 40 V
Vce Saturation (Max) @ Ib, Ic 135mV @ 400mA, 4A 130mV @ 400mA, 4A 220mV @ 400mA, 4A
Current - Collector Cutoff (Max) 100nA (ICBO) 100nA (ICBO) 10µA
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 1A, 2V 200 @ 1A, 2V 220 @ 1A, 2V
Power - Max 830 mW 830 mW 830 mW
Frequency - Transition 140MHz 140MHz 100MHz
Operating Temperature -55°C ~ 150°C (TJ) -55°C ~ 150°C (TJ) -55°C ~ 150°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount
Package / Case 8-SMD, Flat Lead 8-SMD, Flat Lead 8-SMD, Flat Lead
Supplier Device Package ChipFET™ ChipFET™ ChipFET™
