Product Introduction

Overview

The PMBT3904VS/S711115 is an NPN switching transistor produced by Nexperia USA Inc., a leading semiconductor company. This transistor is housed in a small SOT23 Surface-Mounted Device (SMD) plastic package, making it suitable for a wide range of applications where space is limited. It is designed for general switching and amplification purposes, offering a balance of performance and compact design.

Key Specifications

ParameterValue
Collector Current (IC)200 mA
Collector-Emitter Voltage (VCEO)40 V
Package TypeSOT23
Package Size2.9 x 1.3 x 1 mm
Channel TypeNPN
Total Power Dissipation (Ptot)250 mW
DC Current Gain (hFE)100 to 300
Junction Temperature (TJ)150°C
Transition Frequency (fT)300 MHz
AEC-Q101 QualifiedYes

Key Features

  • Compact SOT23 Package: Ideal for space-constrained applications.
  • High Collector Current: Up to 200 mA, suitable for various switching and amplification tasks.
  • High Collector-Emitter Voltage: Rated at 40 V, providing robust performance in different operating conditions.
  • AEC-Q101 Qualified: Ensures reliability and performance in automotive applications.
  • High Transition Frequency: Up to 300 MHz, making it suitable for high-frequency applications.

Applications

The PMBT3904VS/S711115 transistor is versatile and can be used in a variety of applications across different industries, including:

  • Automotive: Suitable for automotive systems due to its AEC-Q101 qualification.
  • Industrial: Used in industrial control systems, power supplies, and other industrial electronics.
  • Consumer Electronics: Found in mobile devices, wearables, and other consumer electronic products.
  • Power and Computing: Used in power management circuits and computing hardware.

Q & A

  1. What is the collector current capability of the PMBT3904VS/S711115 transistor?
    The collector current capability is up to 200 mA.
  2. What is the maximum collector-emitter voltage for this transistor?
    The maximum collector-emitter voltage is 40 V.
  3. What package type is used for the PMBT3904VS/S711115 transistor?
    The transistor is housed in a SOT23 Surface-Mounted Device (SMD) plastic package.
  4. Is the PMBT3904VS/S711115 transistor AEC-Q101 qualified?
    Yes, it is AEC-Q101 qualified, making it suitable for automotive applications.
  5. What is the transition frequency of the PMBT3904VS/S711115 transistor?
    The transition frequency is up to 300 MHz.
  6. What are the typical applications of the PMBT3904VS/S711115 transistor?
    It is used in automotive, industrial, consumer electronics, power, and computing applications.
  7. What is the total power dissipation of the PMBT3904VS/S711115 transistor?
    The total power dissipation is 250 mW.
  8. What is the DC current gain (hFE) of the PMBT3904VS/S711115 transistor?
    The DC current gain ranges from 100 to 300.
  9. What is the junction temperature limit for the PMBT3904VS/S711115 transistor?
    The junction temperature limit is 150°C.
  10. Where can I find more detailed specifications and datasheets for the PMBT3904VS/S711115 transistor?
    You can find detailed specifications and datasheets on the official Nexperia website or through distributors like Digi-Key and Mouser.
