PMBT2222AYS115
  • Share:

NXP USA Inc. PMBT2222AYS115

Manufacturer No:
PMBT2222AYS115
Manufacturer:
NXP USA Inc.
Package:
Bulk
Description:
SMALL SIGNAL BIPOLAR TRANSISTOR
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The PMBT2222AYS115 is a small signal bipolar transistor manufactured by NXP USA Inc. This component is part of NXP's extensive portfolio of discrete semiconductor products. It is designed to provide high performance and reliability in various electronic applications.

Key Specifications

ParameterValue
Type NumberPMBT2222AYS115
PackageSOT23 (TO-236AB)
Channel TypeNPN
Maximum Collector Current (I_C)600 mA
Maximum Collector-Emitter Voltage (V_CE)40 V
Minimum Current Gain (h_FE)100
Maximum Current Gain (h_FE)300
Maximum Junction Temperature (T_J)150°C
Automotive QualifiedAEC-Q101 qualified

Key Features

  • High current capability up to 600 mA
  • Low voltage operation up to 40 V
  • AEC-Q101 qualified, making it suitable for automotive applications
  • Compact SOT23 package for space-saving designs
  • High current gain (h_FE) range from 100 to 300

Applications

The PMBT2222AYS115 is versatile and can be used in a variety of applications, including:

  • Automotive systems: Due to its AEC-Q101 qualification, it is suitable for use in automotive electronics.
  • Industrial control: It can be used in switching and linear amplification circuits.
  • Consumer electronics: Ideal for general-purpose switching and amplification in consumer devices.
  • Power management: Can be used in power management circuits requiring high current and low voltage operation.

Q & A

  1. What is the PMBT2222AYS115?
    The PMBT2222AYS115 is a small signal bipolar transistor manufactured by NXP USA Inc.
  2. What package type does the PMBT2222AYS115 use?
    The PMBT2222AYS115 uses the SOT23 (TO-236AB) package.
  3. What is the maximum collector current of the PMBT2222AYS115?
    The maximum collector current is 600 mA.
  4. Is the PMBT2222AYS115 automotive qualified?
    Yes, it is AEC-Q101 qualified.
  5. What are the typical applications of the PMBT2222AYS115?
    It is used in automotive systems, industrial control, consumer electronics, and power management circuits.
  6. What is the maximum collector-emitter voltage of the PMBT2222AYS115?
    The maximum collector-emitter voltage is 40 V.
  7. What is the current gain range of the PMBT2222AYS115?
    The current gain (h_FE) range is from 100 to 300.
  8. What is the maximum junction temperature of the PMBT2222AYS115?
    The maximum junction temperature is 150°C.
  9. Where can I find more detailed specifications for the PMBT2222AYS115?
    You can find detailed specifications in the datasheet available on the NXP or Nexperia websites.
  10. Is the PMBT2222AYS115 RoHS compliant?
    Yes, the PMBT2222AYS115 is RoHS compliant.
