NXP USA Inc. BC856BMB315

Manufacturer No:
BC856BMB315
Manufacturer:
NXP USA Inc.
Package:
Bulk
Description:
BC856B
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The BC856BMB315 is a bipolar junction transistor (BJT) produced by NXP USA Inc. It belongs to the BC856 series, which is known for its high performance and reliability in various electronic applications. This transistor is a surface-mount device, making it suitable for modern electronic designs that require compact and efficient components.

Key Specifications

ParameterValueUnits
Collector-Base Voltage (VCBO)80V
Collector-Emitter Voltage (VCEO)65V
Base-Emitter Voltage (VBE(SAT)) at IC=10mA, IB=0.5mA0.7V
Collector-Emitter Saturation Voltage (VCE(SAT)) at IC=10mA, IB=0.5mA0.30V
Thermal Resistance (ΘJA)375°C/W
PackageSurface Mount

Key Features

  • High Collector-Base Voltage: Up to 80V, making it suitable for high-voltage applications.
  • Low Saturation Voltage: VCE(SAT) as low as 0.30V, which helps in reducing power consumption.
  • Compact Surface Mount Package: Ideal for modern PCB designs requiring minimal space.
  • High Reliability: Designed to operate reliably under various environmental conditions.

Applications

The BC856BMB315 transistor is versatile and can be used in a variety of applications, including:

  • Amplifier Circuits: Due to its high gain and low noise characteristics.
  • Switching Circuits: For its fast switching times and low saturation voltage.
  • Automotive Electronics: In systems requiring high reliability and durability.
  • Industrial Control Systems: For applications needing robust and efficient transistor performance.

Q & A

  1. What is the collector-base voltage rating of the BC856BMB315 transistor?
    The collector-base voltage (VCBO) rating is 80V.
  2. What is the typical collector-emitter saturation voltage (VCE(SAT)) of the BC856BMB315?
    The typical VCE(SAT) at IC=10mA and IB=0.5mA is 0.30V.
  3. What type of package does the BC856BMB315 come in?
    The BC856BMB315 comes in a surface mount package.
  4. What are some common applications of the BC856BMB315 transistor?
    It is commonly used in amplifier circuits, switching circuits, automotive electronics, and industrial control systems.
  5. Who is the manufacturer of the BC856BMB315 transistor?
    The manufacturer is NXP USA Inc.
  6. What is the thermal resistance (ΘJA) of the BC856BMB315 transistor?
    The thermal resistance (ΘJA) is 375 °C/W.
  7. What is the base-emitter saturation voltage (VBE(SAT)) of the BC856BMB315 at IC=10mA and IB=0.5mA?
    The VBE(SAT) at IC=10mA and IB=0.5mA is 0.7V.
  8. Is the BC856BMB315 suitable for high-voltage applications?
    Yes, it is suitable for high-voltage applications due to its high collector-base and collector-emitter voltage ratings.
  9. What are the benefits of using the BC856BMB315 in modern electronic designs?
    The benefits include its compact surface mount package, high reliability, and low power consumption.
  10. Where can I find detailed specifications and datasheets for the BC856BMB315?
    Detailed specifications and datasheets can be found on the official NXP website or through authorized distributors like Central Semiconductor and Inxpic.
