Overview
The PUSBM5V5X4-TL,115 is a high-speed USB OTG (On-The-Go) ElectroStatic Discharge (ESD) protection diode array manufactured by Nexperia USA Inc. This component is designed to protect USB 2.0 interfaces from ESD events, ensuring the reliability and longevity of the connected devices. The PUSBM5V5X4-TL,115 is part of the PUSBMxX4-TL series, which features four 4-channel ESD diode arrays.
Key Specifications
| Parameter | Value |
|---|---|
| Package Type | DFN1616-6 (Surface Mount) |
| Clamp Voltage | 12V |
| Peak Pulse Current (Ipp) | 3A (8/20µs) |
| Channels | 4 |
| Interface Protection | USB 2.0 OTG |
| Manufacturer | Nexperia USA Inc. |
Key Features
- High-speed USB OTG ESD protection
- Four 4-channel ESD diode arrays
- 12V clamp voltage and 3A peak pulse current (8/20µs)
- Surface mount DFN1616-6 package
- Designed for USB 2.0 interfaces
Applications
The PUSBM5V5X4-TL,115 is suitable for various applications requiring ESD protection for USB 2.0 OTG interfaces, including:
- Portable electronics such as smartphones, tablets, and laptops
- Consumer electronics like digital cameras and audio devices
- Industrial control systems and automation equipment
- Medical devices with USB connectivity
Q & A
- What is the primary function of the PUSBM5V5X4-TL,115? The primary function is to provide ESD protection for USB 2.0 OTG interfaces.
- What is the clamp voltage of the PUSBM5V5X4-TL,115? The clamp voltage is 12V.
- How many channels does the PUSBM5V5X4-TL,115 have? It has four channels.
- What is the peak pulse current (Ipp) of the PUSBM5V5X4-TL,115? The peak pulse current is 3A (8/20µs).
- What package type does the PUSBM5V5X4-TL,115 use? It uses a surface mount DFN1616-6 package.
- Who is the manufacturer of the PUSBM5V5X4-TL,115? The manufacturer is Nexperia USA Inc.
- What interfaces does the PUSBM5V5X4-TL,115 protect? It protects USB 2.0 OTG interfaces.
- What are some common applications for the PUSBM5V5X4-TL,115? Common applications include portable electronics, consumer electronics, industrial control systems, and medical devices.
- Is the PUSBM5V5X4-TL,115 suitable for high-speed USB applications? Yes, it is designed for high-speed USB OTG applications.
- Where can I find detailed specifications for the PUSBM5V5X4-TL,115? Detailed specifications can be found on the datasheet available from sources like Digi-Key, Mouser, and the manufacturer's official website.
