Product Introduction

Overview

The PUMH9/ZL135 is a pre-biased bipolar transistor array produced by Nexperia USA Inc. This component is designed as a dual NPN transistor with built-in bias resistors, simplifying circuit design and reducing the overall component count. It is packaged in a 6-TSSOP (SC-88, SOT-363) surface mount configuration, making it suitable for a variety of electronic applications where space is limited.

Key Specifications

ParameterValue
Transistor TypeDual NPN
Maximum Collector Current (Ic)100 mA
Maximum Collector-Emitter Voltage (Vce)50 V
Transition Frequency (fT)230 MHz
Maximum Power Dissipation (Pd)300 mW
Package/Case6-TSSOP (SC-88, SOT-363)
Resistor - Base (R1)10 kΩ

Key Features

  • Built-in bias resistors simplify circuit design and reduce component count.
  • High output current capability of up to 100 mA.
  • High transition frequency of 230 MHz, suitable for high-frequency applications.
  • Compact 6-TSSOP (SC-88, SOT-363) surface mount package.
  • Maximum power dissipation of 300 mW.

Applications

The PUMH9/ZL135 is versatile and can be used in various electronic circuits, including audio amplifiers, switching circuits, and general-purpose amplification. Its high transition frequency and built-in bias resistors make it particularly suitable for applications requiring high-frequency performance and simplified circuit design.
