Nexperia USA Inc. BC807-16QBH-QZ

Manufacturer No:
BC807-16QBH-QZ
Manufacturer:
Nexperia USA Inc.
Package:
Tape & Reel (TR)
Description:
TRANS PNP 45V 0.5A DFN1110D-3
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The BC807-16QBH-QZ is a PNP general-purpose bipolar transistor manufactured by Nexperia USA Inc. This transistor is part of the BC807QBH-Q series, which is specifically designed for automotive applications and is qualified according to AEC-Q101 standards. The device is packaged in a small DFN1110D-3 (SOT8015) package, making it suitable for space-constrained designs while maintaining high performance.

Key Specifications

Type number Package version Package name Size (mm) T J [max] (°C)
BC807-16QBH-Q SOT8015 DFN1110D-3 1.1 x 1 x 0.48 175
Type number Orderable part number Status Marking Package Package information Reflow-/Wave soldering Packing
BC807-16QBH-Q BC807-16QBH-QZ (934664310147) Active F6 DFN1110D-3 (SOT8015) SOT8015 REFLOW_BG-BD-1 SOT8015_147

Key Features

  • Automotive Qualified: Compliant with AEC-Q101 standards, making it suitable for automotive applications.
  • High Current Capability: Supports up to 500 mA of collector current.
  • Low Voltage Drop: Operates with a maximum collector-emitter voltage of 45 V.
  • Compact Package: DFN1110D-3 (SOT8015) package, which is small and leadless, ideal for space-constrained designs.
  • High Temperature Rating: Maximum junction temperature of 175°C.
  • RoHS Compliant: Meets RoHS (Restriction of Hazardous Substances) regulations.

Applications

  • Automotive Systems: Suitable for various automotive applications such as power management, sensor interfaces, and general-purpose switching and amplification.
  • Industrial Control: Used in industrial control systems for switching and amplification purposes.
  • Consumer Electronics: Can be used in consumer electronics for general-purpose transistor applications.

Q & A

  1. What is the maximum collector current of the BC807-16QBH-QZ transistor?

    The maximum collector current is 500 mA.

  2. What package type is used for the BC807-16QBH-QZ transistor?

    The transistor is packaged in a DFN1110D-3 (SOT8015) package.

  3. Is the BC807-16QBH-QZ transistor RoHS compliant?

    Yes, the transistor is RoHS compliant.

  4. What is the maximum junction temperature for the BC807-16QBH-QZ transistor?

    The maximum junction temperature is 175°C.

  5. What are the typical applications for the BC807-16QBH-QZ transistor?

    Typical applications include automotive systems, industrial control, and consumer electronics.

  6. Is the BC807-16QBH-QZ transistor qualified for automotive use?

    Yes, it is qualified according to AEC-Q101 standards.

  7. What is the collector-emitter voltage rating for the BC807-16QBH-QZ transistor?

    The collector-emitter voltage rating is 45 V.

  8. How can I obtain samples of the BC807-16QBH-QZ transistor?

    Samples can be ordered through Nexperia's sales organization or through their network of global and regional distributors.

  9. What type of soldering is recommended for the BC807-16QBH-QZ transistor?

    Reflow soldering is recommended, following the REFLOW_BG-BD-1 profile.

  10. Where can I find detailed documentation for the BC807-16QBH-QZ transistor?

    Detailed documentation, including datasheets and application notes, can be found on Nexperia's official website.

Product Attributes

Transistor Type:PNP
Current - Collector (Ic) (Max):500 mA
Voltage - Collector Emitter Breakdown (Max):45 V
Vce Saturation (Max) @ Ib, Ic:700mV @ 50mA, 500mA
Current - Collector Cutoff (Max):100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 100mA, 1V
Power - Max:420 mW
Frequency - Transition:80MHz
Operating Temperature:175°C (TJ)
Mounting Type:Surface Mount, Wettable Flank
Package / Case:3-XDFN Exposed Pad
Supplier Device Package:DFN1110D-3
