Overview
The USBULC6-2M6, produced by STMicroelectronics, is a monolithic, application-specific discrete device designed for the ESD (Electrostatic Discharge) protection of high-speed interfaces. This component is particularly suited for protecting sensitive electronics from voltage surges and ESD events, ensuring the reliability and longevity of the system.
Key Specifications
| Parameter | Value |
|---|---|
| Package Type | UQFN-6 |
| ESD Protection | 15 kV |
| Line Capacitance | 0.65 pF at F = 240 MHz |
| Clamping Voltage | 17 V |
| Peak Pulse Current (Ipp) | 5 A (8/20 µs) |
| Operating Voltage | Up to 5 V |
| Package Dimensions | 1.45 x 1.0 mm |
Key Features
- Ultra-low line capacitance of 0.65 pF at 240 MHz, ensuring minimal signal distortion.
- High ESD protection level of 15 kV, safeguarding against electrostatic discharge.
- Low clamping voltage of 17 V to protect sensitive electronics.
- Compact UQFN-6 package, ideal for space-constrained designs.
- RoHS compliant, making it suitable for environmentally friendly applications.
Applications
The USBULC6-2M6 is designed for use in various high-speed interface applications, including:
- USB ports and connectors.
- High-speed data lines and communication interfaces.
- Sensitive electronic circuits requiring robust ESD protection.
- Consumer electronics, such as smartphones, tablets, and laptops.
- Industrial and automotive systems where reliability is critical.
Q & A
- What is the primary function of the USBULC6-2M6?
The primary function of the USBULC6-2M6 is to provide ESD protection for high-speed interfaces. - What is the ESD protection level of the USBULC6-2M6?
The ESD protection level is 15 kV. - What is the line capacitance of the USBULC6-2M6?
The line capacitance is 0.65 pF at 240 MHz. - What is the clamping voltage of the USBULC6-2M6?
The clamping voltage is 17 V. - What is the peak pulse current (Ipp) of the USBULC6-2M6?
The peak pulse current (Ipp) is 5 A (8/20 µs). - What package type does the USBULC6-2M6 come in?
The USBULC6-2M6 comes in a UQFN-6 package. - Is the USBULC6-2M6 RoHS compliant?
Yes, the USBULC6-2M6 is RoHS compliant. - What are some common applications for the USBULC6-2M6?
Common applications include USB ports, high-speed data lines, and sensitive electronic circuits in consumer electronics, industrial, and automotive systems. - What are the dimensions of the UQFN-6 package?
The dimensions of the UQFN-6 package are 1.45 x 1.0 mm. - What is the operating voltage range for the USBULC6-2M6?
The operating voltage range is up to 5 V.
