Overview
The PMEG2005AESF/S711315 is a high-performance Schottky rectifier diode manufactured by NXP USA Inc. This component is designed to provide efficient rectification in various electronic circuits. With its compact DSN0603-2 package, it is ideal for applications where space is limited but high performance is required.
Key Specifications
| Parameter | Value |
|---|---|
| Diode Type | Schottky Rectifier |
| Voltage - DC Reverse (Vr) (Max) | 20 V |
| Current - Average Rectified (Io) | 200 mA |
| Voltage - Forward (Vf) (Max) @ If | |
| Package | DSN0603-2 |
| RoHS Status | RoHS Compliant |
Key Features
- High efficiency Schottky rectification
- Low forward voltage drop (typically around 0.4 V at 200 mA)
- Compact DSN0603-2 package for space-saving designs
- RoHS compliant, ensuring environmental sustainability
- High reliability and durability in various operating conditions
Applications
The PMEG2005AESF/S711315 is suitable for a wide range of applications, including:
- Power supply circuits requiring efficient rectification
- Switch-mode power supplies (SMPS)
- DC-DC converters
- Automotive and industrial power systems
- Consumer electronics where compact size and high efficiency are crucial
