Overview
The P89LPC912FDH,129 is a microcontroller from NXP USA Inc., part of the LPC900 series. This device is designed for a wide range of applications requiring low power consumption, high performance, and advanced peripherals. The P89LPC912FDH,129 features an 80C51 CPU with a maximum clock frequency of 7.3728 MHz, making it suitable for various embedded systems and IoT projects.
Key Specifications
| Specification | Value |
|---|---|
| Microcontroller Family | LPC900 Series |
| CPU Type | 80C51 |
| Maximum Clock Frequency | 7.3728 MHz |
| Program Memory | 8 KB Flash |
| Data Memory | 512 Bytes RAM |
| Number of I/O Pins | 20 |
| Communication Interfaces | UART, SPI, I2C |
| Operating Voltage | 2.4 V to 3.6 V |
| Operating Temperature Range | -40°C to 85°C |
| Package Type | TSSOP20 |
Key Features
- Low Power Consumption: Optimized for low power applications, making it ideal for battery-powered devices.
- Advanced Peripherals: Includes UART, SPI, and I2C communication interfaces for versatile connectivity.
- High Performance: 80C51 CPU with a maximum clock frequency of 7.3728 MHz ensures efficient processing.
- Programmable Flash Memory: 8 KB of Flash memory for program storage.
- On-Chip Debugging: Supports on-chip debugging for easier development and debugging.
Applications
- Embedded Systems: Suitable for a variety of embedded system applications due to its low power and high performance capabilities.
- IoT Devices: Ideal for Internet of Things (IoT) devices that require efficient processing and low power consumption.
- Industrial Automation: Can be used in industrial automation projects requiring reliable and efficient microcontrollers.
- Consumer Electronics: Used in various consumer electronics such as remote controls, appliances, and more.
Q & A
- What is the maximum clock frequency of the P89LPC912FDH,129 microcontroller?
The maximum clock frequency is 7.3728 MHz. - How much program memory does the P89LPC912FDH,129 have?
The P89LPC912FDH,129 has 8 KB of Flash memory for program storage. - What are the communication interfaces available on the P89LPC912FDH,129?
The device includes UART, SPI, and I2C communication interfaces. - What is the operating voltage range of the P89LPC912FDH,129?
The operating voltage range is from 2.4 V to 3.6 V. - What is the package type of the P89LPC912FDH,129?
The package type is TSSOP20. - Is the P89LPC912FDH,129 suitable for IoT applications?
Yes, it is suitable for IoT applications due to its low power consumption and high performance. - Does the P89LPC912FDH,129 support on-chip debugging?
Yes, it supports on-chip debugging. - What is the temperature range for the P89LPC912FDH,129?
The operating temperature range is from -40°C to 85°C. - How much RAM does the P89LPC912FDH,129 have?
The device has 512 Bytes of RAM. - How many I/O pins does the P89LPC912FDH,129 have?
The device has 20 I/O pins.
