Overview
The BAT254,115 is a Schottky barrier diode produced by NXP USA Inc. This component is designed to provide high efficiency and low forward voltage drop, making it suitable for a variety of applications requiring fast switching and low power loss. The diode is packaged in a 2-pin SOD (Small Outline Diode) format and is compliant with the latest environmental standards, including ROHS certification and the REACH directive, ensuring it is a green and environmentally friendly option.
Key Specifications
| Parameter | Value |
|---|---|
| Manufacturer | NXP USA Inc. |
| Part Number | BAT254,115 |
| Diode Type | Schottky Barrier Diode |
| Maximum Forward Voltage (Vf) | 0.34 V (typical at 100 mA) |
| Maximum Reverse Voltage (Vr) | 30 V |
| Maximum Forward Current (If) | 0.2 A |
| Package Type | 2-Pin SOD (Tape & Reel) |
| Lifecycle Status | EOL (End of Life) |
Key Features
- Low forward voltage drop, typically 0.34 V at 100 mA, ensuring high efficiency and low power loss.
- Fast switching times, making it suitable for high-frequency applications.
- Compliant with ROHS and REACH directives, ensuring environmental sustainability.
- Compact 2-pin SOD package, ideal for space-constrained designs.
- Maximum reverse voltage of 30 V, providing robust protection against reverse bias conditions.
Applications
- Power supplies and DC-DC converters where low forward voltage drop is crucial.
- High-frequency switching circuits, such as in audio and video equipment.
- Rectifier circuits in automotive and industrial applications.
- Protection circuits against back EMF in inductive loads.
- General-purpose rectification in various electronic devices.
Q & A
- What is the maximum forward current of the BAT254,115?
The maximum forward current of the BAT254,115 is 0.2 A.
- What is the typical forward voltage drop of the BAT254,115?
The typical forward voltage drop of the BAT254,115 is 0.34 V at 100 mA.
- What is the package type of the BAT254,115?
The BAT254,115 is packaged in a 2-pin SOD (Small Outline Diode) format.
- Is the BAT254,115 compliant with environmental standards?
Yes, the BAT254,115 is compliant with ROHS and REACH directives.
- What is the lifecycle status of the BAT254,115?
The BAT254,115 is currently at the End of Life (EOL) stage.
- What are some common applications of the BAT254,115?
The BAT254,115 is commonly used in power supplies, DC-DC converters, high-frequency switching circuits, and general-purpose rectification.
- What is the maximum reverse voltage of the BAT254,115?
The maximum reverse voltage of the BAT254,115 is 30 V.
- Why is the BAT254,115 preferred in high-frequency applications?
The BAT254,115 is preferred in high-frequency applications due to its fast switching times and low forward voltage drop.
- Can the BAT254,115 be used in automotive applications?
Yes, the BAT254,115 can be used in automotive applications due to its robust specifications and environmental compliance.
- What is the significance of the SOD package in the BAT254,115?
The SOD package of the BAT254,115 is compact and ideal for space-constrained designs, making it versatile for various applications.
