NXP USA Inc. 2PA1774RMB,315

Manufacturer No:
2PA1774RMB,315
Manufacturer:
NXP USA Inc.
Package:
Bulk
Description:
NOW NEXPERIA 2PA1774RMB - SMALL
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The 2PA1774RMB,315 is a PNP bipolar junction transistor (BJT) manufactured by Nexperia. This transistor is part of the Automotive, AEC-Q101 series, ensuring it meets stringent automotive quality standards. It is designed for general-purpose applications and features a compact DFN1006B-3 package, making it suitable for surface mount technology.

This transistor is characterized by its high reliability and performance, with a maximum collector-emitter voltage of 40V and a maximum collector current of 100mA. It operates within a temperature range of up to 150°C (TJ), making it robust for various environmental conditions.

Key Specifications

Parameter Value
Part Number 2PA1774RMB,315
Manufacturer Nexperia
Transistor Type PNP
Voltage - Collector Emitter Breakdown (Max) 40V
Vce Saturation (Max) @ Ib, Ic 200mV @ 5mA, 50mA
Current - Collector (Ic) (Max) 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 1mA, 6V
Current - Collector Cutoff (Max) 100nA (ICBO)
Power - Max 250mW
Frequency - Transition 100MHz
Operating Temperature 150°C (TJ)
Mounting Type Surface Mount
Package / Case DFN1006B-3, SC-101, SOT-883
Packaging Tape & Reel (TR)

Key Features

  • High DC Current Gain: The transistor has a minimum DC current gain of 180 @ 1mA, 6V, ensuring efficient current amplification.
  • Low Vce Saturation: With a Vce saturation of 200mV @ 5mA, 50mA, it minimizes power losses during operation.
  • High Frequency Capability: It has a transition frequency of 100MHz, making it suitable for high-frequency applications.
  • Compact Package: The DFN1006B-3 package is ideal for surface mount technology, saving space in modern electronic designs.
  • AEC-Q101 Qualified: This transistor meets the Automotive Electronics Council’s Q101 standard, ensuring reliability and performance in automotive applications.

Applications

  • Inverters: Used in inverter circuits due to its high current gain and low saturation voltage.
  • Interface and Driver Circuits: Suitable for driving and interfacing various electronic components due to its high frequency capability.
  • Muting Circuits: Can be used in muting circuits where high current gain and low noise are required.
  • Automotive Electronics: AEC-Q101 qualification makes it suitable for use in automotive systems, including power management and signal processing.

Q & A

  1. What is the maximum collector-emitter voltage of the 2PA1774RMB,315 transistor?

    The maximum collector-emitter voltage is 40V.

  2. What is the maximum collector current of the 2PA1774RMB,315 transistor?

    The maximum collector current is 100mA.

  3. What is the DC current gain of the 2PA1774RMB,315 transistor?

    The minimum DC current gain is 180 @ 1mA, 6V.

  4. What is the operating temperature range of the 2PA1774RMB,315 transistor?

    The operating temperature range is up to 150°C (TJ).

  5. What package types are available for the 2PA1774RMB,315 transistor?

    The transistor is available in DFN1006B-3, SC-101, and SOT-883 packages.

  6. Is the 2PA1774RMB,315 transistor AEC-Q101 qualified?

    Yes, it is AEC-Q101 qualified, making it suitable for automotive applications.

  7. What is the transition frequency of the 2PA1774RMB,315 transistor?

    The transition frequency is 100MHz.

  8. What is the maximum power dissipation of the 2PA1774RMB,315 transistor?

    The maximum power dissipation is 250mW.

  9. What is the Vce saturation voltage of the 2PA1774RMB,315 transistor?

    The Vce saturation voltage is 200mV @ 5mA, 50mA.

  10. What are the typical applications of the 2PA1774RMB,315 transistor?

    Typical applications include inverters, interface and driver circuits, muting circuits, and automotive electronics.

Product Attributes

Transistor Type:PNP
Current - Collector (Ic) (Max):100 mA
Voltage - Collector Emitter Breakdown (Max):40 V
Vce Saturation (Max) @ Ib, Ic:200mV @ 5mA, 50mA
Current - Collector Cutoff (Max):100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce:180 @ 1mA, 6V
Power - Max:250 mW
Frequency - Transition:100MHz
Operating Temperature:150°C (TJ)
Mounting Type:Surface Mount
Package / Case:SC-101, SOT-883
Supplier Device Package:DFN1006-3
0 Remaining View Similar

In Stock

$0.04
15,577

Please send RFQ , we will respond immediately.

Same Series
2PA1774SMB,315
2PA1774SMB,315
NOW NEXPERIA 2PA1774SMB - SMALL
2PA1774QMB,315
2PA1774QMB,315
TRANS PNP 40V 0.1A DFN1006B-3

Similar Products

Part Number 2PA1774RMB,315 2PA1774SMB,315 2PA1774QMB,315 2PA1774RM,315
Manufacturer NXP USA Inc. NXP USA Inc. Nexperia USA Inc. Nexperia USA Inc.
Product Status Active Active Active Active
Transistor Type PNP PNP PNP PNP
Current - Collector (Ic) (Max) 100 mA 100 mA 100 mA 100 mA
Voltage - Collector Emitter Breakdown (Max) 40 V 40 V 40 V 40 V
Vce Saturation (Max) @ Ib, Ic 200mV @ 5mA, 50mA 200mV @ 5mA, 50mA 200mV @ 5mA, 50mA 200mV @ 5mA, 50mA
Current - Collector Cutoff (Max) 100nA (ICBO) 100nA (ICBO) 100nA (ICBO) 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 180 @ 1mA, 6V 270 @ 1mA, 6V 120 @ 1mA, 6V 180 @ 1mA, 6V
Power - Max 250 mW 250 mW 250 mW 430 mW
Frequency - Transition 100MHz 100MHz 100MHz 100MHz
Operating Temperature 150°C (TJ) 150°C (TJ) 150°C (TJ) 150°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount
Package / Case SC-101, SOT-883 SC-101, SOT-883 3-XFDFN SC-101, SOT-883
Supplier Device Package DFN1006-3 DFN1006-3 DFN1006B-3 SOT-883
