Nexperia USA Inc. PBSS5580PA,115

Manufacturer No:
PBSS5580PA,115
Manufacturer:
Nexperia USA Inc.
Package:
Tape & Reel (TR)
Description:
TRANS PNP 80V 4A 3HUSON
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The PBSS5580PA,115 is a PNP bipolar junction transistor (BJT) manufactured by Nexperia USA Inc. This component is designed to operate in a variety of applications requiring high reliability and performance. With its robust specifications, it is suitable for use in automotive, industrial, and consumer electronics.

Key Specifications

ParameterValue
Transistor TypePNP Bipolar Junction Transistor
Maximum Collector-Emitter Voltage (Vceo)80 V
Maximum Collector Current (Ic)4 A
Maximum Power Dissipation (Ptot)2100 mW
Package Type3-Pin HUSON

Key Features

  • High collector current capability of up to 4 A.
  • Maximum collector-emitter voltage of 80 V, making it suitable for high-voltage applications.
  • Compact 3-Pin HUSON package, which is ideal for space-constrained designs.
  • High power dissipation of 2100 mW, ensuring reliable operation under various load conditions.

Applications

The PBSS5580PA,115 is versatile and can be used in a range of applications, including:

  • Automotive systems: Suitable for use in vehicle electronics due to its robust specifications and reliability.
  • Industrial electronics: Ideal for motor control, power supplies, and other industrial applications requiring high current and voltage handling.
  • Consumer electronics: Can be used in various consumer devices that require reliable and efficient power switching.

Q & A

  1. What is the maximum collector-emitter voltage of the PBSS5580PA,115?
    The maximum collector-emitter voltage is 80 V.
  2. What is the maximum collector current of the PBSS5580PA,115?
    The maximum collector current is 4 A.
  3. What is the package type of the PBSS5580PA,115?
    The package type is 3-Pin HUSON.
  4. What is the maximum power dissipation of the PBSS5580PA,115?
    The maximum power dissipation is 2100 mW.
  5. In which applications can the PBSS5580PA,115 be used?
    It can be used in automotive, industrial, and consumer electronics applications.
  6. Who is the manufacturer of the PBSS5580PA,115?
    The manufacturer is Nexperia USA Inc.
  7. Where can I find the datasheet for the PBSS5580PA,115?
    You can find the datasheet on the Nexperia website or through authorized distributors like Mouser, Digi-Key, and Arrow Electronics.
  8. Is the PBSS5580PA,115 RoHS compliant?
    Yes, the PBSS5580PA,115 is RoHS compliant.
  9. What are the typical uses of a PNP BJT like the PBSS5580PA,115?
    PNP BJTs are typically used for power switching, amplification, and as drivers in various electronic circuits.
  10. How do I ensure the reliability of the PBSS5580PA,115 in my design?
    Ensure proper heat sinking, follow the recommended operating conditions, and use appropriate protection circuits to ensure reliability.

Product Attributes

Transistor Type:PNP
Current - Collector (Ic) (Max):4 A
Voltage - Collector Emitter Breakdown (Max):80 V
Vce Saturation (Max) @ Ib, Ic:420mV @ 200mA, 4A
Current - Collector Cutoff (Max):100nA
DC Current Gain (hFE) (Min) @ Ic, Vce:140 @ 2A, 2V
Power - Max:2.1 W
Frequency - Transition:110MHz
Operating Temperature:150°C (TJ)
Mounting Type:Surface Mount
Package / Case:3-PowerUDFN
Supplier Device Package:3-HUSON (2x2)
0 Remaining View Similar

In Stock

$0.54
1,251

Please send RFQ , we will respond immediately.

Similar Products

Part Number PBSS5580PA,115 PBSS4580PA,115 PBSS5560PA,115
Manufacturer Nexperia USA Inc. Nexperia USA Inc. Nexperia USA Inc.
Product Status Active Active Active
Transistor Type PNP NPN PNP
Current - Collector (Ic) (Max) 4 A 5.6 A 5 A
Voltage - Collector Emitter Breakdown (Max) 80 V 80 V 60 V
Vce Saturation (Max) @ Ib, Ic 420mV @ 200mA, 4A 320mV @ 280mA, 5.6A 450mV @ 250mA, 5A
Current - Collector Cutoff (Max) 100nA 100nA 100nA
DC Current Gain (hFE) (Min) @ Ic, Vce 140 @ 2A, 2V 150 @ 2A, 2V 150 @ 2A, 2V
Power - Max 2.1 W 2.1 W 2.1 W
Frequency - Transition 110MHz 155MHz 90MHz
Operating Temperature 150°C (TJ) 150°C (TJ) 150°C (TJ)
Mounting Type Surface Mount Surface Mount Surface Mount
Package / Case 3-PowerUDFN 3-PowerUDFN 3-PowerUDFN
Supplier Device Package 3-HUSON (2x2) 3-HUSON (2x2) 3-HUSON (2x2)
