Overview
The BAS521/S500X is a high-voltage switching diode manufactured by Nexperia USA Inc. This diode is fabricated using planar technology and is encapsulated in a SOD523 (SC-79) ultra-small Surface-Mounted Device (SMD) plastic package. It is designed for high-voltage applications and offers compact size and reliable performance.
Key Specifications
| Parameter | Value |
|---|---|
| Package | SOD523 (SC-79) |
| Forward Current (IF) | 1 A |
| Reverse Voltage (VR) | 200 V |
| Forward Voltage (VF) | 1.2 V (typical at IF = 1 A) |
| Reverse Recovery Time (trr) | 50 ns (typical) |
| Operating Temperature Range | -55°C to +150°C |
Key Features
- High-voltage switching capability up to 200 V
- Ultra-small SOD523 (SC-79) package for compact designs
- Planar technology for reliable and stable performance
- Low forward voltage drop (VF) of 1.2 V typical at IF = 1 A
- Fast reverse recovery time (trr) of 50 ns typical
- Wide operating temperature range from -55°C to +150°C
Applications
- High-voltage power supplies and converters
- Switching and rectification in industrial and automotive systems
- Consumer electronics requiring high-voltage diodes
- Telecommunications and networking equipment
Q & A
- What is the package type of the BAS521/S500X diode?
The BAS521/S500X diode is encapsulated in a SOD523 (SC-79) ultra-small Surface-Mounted Device (SMD) plastic package. - What is the maximum forward current rating of the BAS521/S500X?
The maximum forward current rating is 1 A. - What is the reverse voltage rating of the BAS521/S500X?
The reverse voltage rating is 200 V. - What is the typical forward voltage drop of the BAS521/S500X at 1 A?
The typical forward voltage drop is 1.2 V at IF = 1 A. - What is the reverse recovery time of the BAS521/S500X?
The reverse recovery time is 50 ns typical. - What is the operating temperature range of the BAS521/S500X?
The operating temperature range is from -55°C to +150°C. - What technology is used in the fabrication of the BAS521/S500X?
The BAS521/S500X is fabricated using planar technology. - Where can the BAS521/S500X be used?
The BAS521/S500X can be used in high-voltage power supplies, switching and rectification in industrial and automotive systems, consumer electronics, and telecommunications equipment. - Why is the SOD523 package beneficial?
The SOD523 package is beneficial due to its ultra-small size, making it ideal for compact designs. - What are the key advantages of the BAS521/S500X?
The key advantages include high-voltage switching capability, low forward voltage drop, fast reverse recovery time, and a wide operating temperature range.
