Overview
The STBR3012W, produced by STMicroelectronics, is a high-voltage rectifier designed for bridge applications. This device is characterized by its consistently reproducible characteristics and intrinsic ruggedness, making it ideal for heavy-duty applications that demand long-term reliability, such as automotive and battery charging systems. The ultra-low conduction losses of the STBR3012W make it particularly suitable for use as an input bridge diode in battery chargers.
Key Specifications
| Parameter | Value |
|---|---|
| Package | D2PAK HV, DO-247 |
| Grade | Industrial |
| RoHS Compliance Grade | Ecopack1, Ecopack2 |
| Junction Temperature (°C) (max) | 175 |
| Operating Temperature (°C) | -40 to 150 (ambient), -40 to 175 (junction) |
| D²PAK HV Creepage Distance (anode to cathode) | 5.38 mm min. (with top coating) |
Key Features
- Ultra-low conduction losses
- Ultra-low reverse losses
- High junction temperature capability (+175 °C)
- D²PAK HV creepage distance (anode to cathode) = 5.38 mm min. (with top coating)
- ECOPACK® compliant (DO-247)
Applications
The STBR3012W is particularly suited for heavy-duty applications, including:
- Automotive systems
- Battery chargers
- Industrial power supplies
- High-reliability bridge rectifier applications
Q & A
- What is the primary application of the STBR3012W?
The STBR3012W is primarily used as an input bridge diode in battery chargers and other heavy-duty applications. - What are the key features of the STBR3012W?
The key features include ultra-low conduction losses, ultra-low reverse losses, high junction temperature capability, and ECOPACK® compliance. - What is the maximum junction temperature of the STBR3012W?
The maximum junction temperature is 175 °C. - What packages are available for the STBR3012W?
The device is available in D2PAK HV and DO-247 packages. - Is the STBR3012W RoHS compliant?
Yes, the STBR3012W is RoHS compliant with Ecopack1 and Ecopack2 grades. - What is the creepage distance for the D²PAK HV package?
The creepage distance (anode to cathode) for the D²PAK HV package is 5.38 mm min. (with top coating). - What are the operating temperature ranges for the STBR3012W?
The operating temperature ranges are -40 to 150 °C (ambient) and -40 to 175 °C (junction). - Where can I find the datasheet for the STBR3012W?
The datasheet can be found on the STMicroelectronics official website, as well as on distributor sites like DigiKey and AllDatasheet. - Is the STBR3012W suitable for automotive applications?
Yes, the STBR3012W is suitable for automotive applications due to its high reliability and ruggedness. - What CAD resources are available for the STBR3012W?
EDA symbols, footprints, and 3D models are available for download to support design activities.
