Overview
The ESD11A5.0DT5G is an Electrostatic Discharge (ESD) protection diode manufactured by onsemi. This component is designed to protect sensitive electronic circuits from damage caused by ESD events. It is packaged in a compact SOT-1123 surface mount format, making it suitable for a wide range of applications where space is limited.
Key Specifications
| Parameter | Value |
|---|---|
| Voltage - Reverse Standoff (Typ) | 5V |
| Voltage - Breakdown (Min) | 6.2V |
| Voltage - Clamping (Max) @ Ipp | 9.5V |
| Current - Peak Pulse (8/20µs) | 1A |
| Package Type | SOT-1123 |
Key Features
- Ultra-small SOT-1123 package for space-saving designs
- High ESD protection capability to safeguard against transient voltage spikes
- Low leakage current to minimize power consumption
- Fast response time to protect sensitive components effectively
Applications
The ESD11A5.0DT5G is ideal for use in various electronic devices and systems that require protection against ESD events. These include:
- Portable electronics such as smartphones, tablets, and laptops
- Consumer electronics like TVs, audio equipment, and gaming consoles
- Automotive systems, including infotainment and navigation systems
- Industrial control and automation equipment
Q & A
- What is the primary function of the ESD11A5.0DT5G?
The primary function is to protect electronic circuits from damage caused by electrostatic discharge (ESD) events. - What is the typical reverse standoff voltage of the ESD11A5.0DT5G?
The typical reverse standoff voltage is 5V. - What is the maximum clamping voltage at peak pulse current?
The maximum clamping voltage at peak pulse current is 9.5V. - What is the peak pulse current rating of the ESD11A5.0DT5G?
The peak pulse current rating is 1A (8/20µs). - In what package type is the ESD11A5.0DT5G available?
The ESD11A5.0DT5G is available in a SOT-1123 surface mount package. - What are some common applications for the ESD11A5.0DT5G?
Common applications include portable electronics, consumer electronics, automotive systems, and industrial control equipment. - Why is the ESD11A5.0DT5G beneficial for space-constrained designs?
The ultra-small SOT-1123 package makes it beneficial for space-constrained designs. - How does the ESD11A5.0DT5G protect against ESD events?
The ESD11A5.0DT5G protects against ESD events by clamping transient voltage spikes to a safe level, thereby safeguarding sensitive components. - What is the minimum breakdown voltage of the ESD11A5.0DT5G?
The minimum breakdown voltage is 6.2V. - Is the ESD11A5.0DT5G suitable for high-speed applications?
Yes, it is suitable due to its fast response time.
