NXP USA Inc. 74LVC1GU04GW-Q100125

Manufacturer No:
74LVC1GU04GW-Q100125
Manufacturer:
NXP USA Inc.
Package:
Bulk
Description:
INVERTER, LVC/LCX/Z SERIES
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The 74LVC1GU04GW-Q100125 is a single-channel inverter integrated circuit (IC) produced by NXP USA Inc., now part of Nexperia. This component is part of the LVC (Low-Voltage CMOS) series, known for its low power consumption and high speed. The 74LVC1GU04GW-Q100125 is designed to operate over a wide voltage range, making it versatile for various digital logic applications.

Key Specifications

Attribute Value
Manufacturer NXP USA Inc. (Nexperia)
Function Inverter
Number of Channels 1
Number of Inputs 1
Package Type 5-TSSOP (Thin Shrink Small Outline Package)
Operating Voltage Range 1.65 V to 5.5 V
High Level Output Current -32 mA
Low Level Output Current 32 mA
Moisture Sensitivity Level (MSL) 3 (168 Hours)
RoHS Status Compliant

Key Features

  • Low Power Consumption: The 74LVC1GU04GW-Q100125 operates with low power, making it suitable for battery-powered devices and energy-efficient designs.
  • High Speed: This IC offers high switching speeds, ensuring fast signal propagation and minimal delay in digital circuits.
  • Wide Operating Voltage Range: Compatible with a range of voltages from 1.65 V to 5.5 V, this component can be used in various digital logic applications.
  • Compact Package: The 5-TSSOP package is compact and space-efficient, ideal for modern electronic designs where board space is limited.
  • RoHS Compliant: This component meets the RoHS (Restriction of Hazardous Substances) directive, ensuring it is environmentally friendly and compliant with regulatory standards.

Applications

  • Digital Logic Circuits: The 74LVC1GU04GW-Q100125 is used in various digital logic circuits where signal inversion is required.
  • Embedded Systems: Suitable for use in embedded systems due to its low power consumption and high speed.
  • Consumer Electronics: Found in consumer electronics such as smartphones, tablets, and other portable devices.
  • Automotive Systems: Used in automotive systems where reliability and low power consumption are critical.
  • Industrial Control Systems: Applied in industrial control systems for signal processing and logic operations.

Q & A

  1. What is the function of the 74LVC1GU04GW-Q100125 IC?

    The 74LVC1GU04GW-Q100125 is a single-channel inverter IC, which means it inverts the input signal to produce an output signal that is the logical opposite of the input.

  2. What is the operating voltage range of this IC?

    The operating voltage range of the 74LVC1GU04GW-Q100125 is from 1.65 V to 5.5 V.

  3. What is the package type of this component?

    The package type is 5-TSSOP (Thin Shrink Small Outline Package).

  4. Is the 74LVC1GU04GW-Q100125 RoHS compliant?
  5. What are the typical applications of this IC?

    This IC is typically used in digital logic circuits, embedded systems, consumer electronics, automotive systems, and industrial control systems.

  6. What is the moisture sensitivity level (MSL) of this component?

    The moisture sensitivity level (MSL) of the 74LVC1GU04GW-Q100125 is 3 (168 Hours).

  7. What are the high and low level output currents of this IC?

    The high level output current is -32 mA, and the low level output current is 32 mA.

  8. Why is the 74LVC1GU04GW-Q100125 preferred in battery-powered devices?
  9. Can the 74LVC1GU04GW-Q100125 be used in high-speed applications?
  10. What is the ECCN (Export Control Classification Number) for this component?

    The ECCN for the 74LVC1GU04GW-Q100125 is EAR99.
