PMEG2020EPK,315
  • Share:

Nexperia USA Inc. PMEG2020EPK,315

Manufacturer No:
PMEG2020EPK,315
Manufacturer:
Nexperia USA Inc.
Package:
Tape & Reel (TR)
Description:
DIODE SCHOTTKY 20V 2A DFN1608D-2
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The PMEG2020EPK,315 is a Schottky diode produced by Nexperia USA Inc., designed for use in discrete semiconductor products. This diode is part of Nexperia's extensive range of Schottky diodes, known for their high performance and reliability. The PMEG2020EPK,315 is particularly suited for applications requiring low forward voltage drop and high surge current capabilities, making it an excellent choice for various electronic systems.

Key Specifications

ParameterValue
Part NumberPMEG2020EPK,315
ManufacturerNexperia USA Inc.
Package Type2-Pin DFN-D
Current Rating2 A
Voltage Rating-
Forward Voltage DropLow (typical for Schottky diodes)
Surge Current CapabilityHigh
AEC-Q101 QualifiedYes
Operating Temperature Range-40°C to 150°C (typical for automotive-grade components)

Key Features

  • Low Forward Voltage Drop: The PMEG2020EPK,315 features a low forward voltage drop, which is characteristic of Schottky diodes, making it efficient for power conversion and rectification applications.
  • High Surge Current Capability: This diode is capable of handling high surge currents, ensuring reliability in demanding applications.
  • AEC-Q101 Qualified: The component is qualified to the AEC-Q101 standard, making it suitable for automotive applications where reliability and performance are critical.
  • Compact Packaging: The 2-Pin DFN-D package is compact and ideal for space-constrained designs, enhancing thermal efficiency and minimizing footprint.

Applications

  • Automotive Systems: Given its AEC-Q101 qualification, this diode is widely used in automotive systems, including power management, rectification, and protection circuits.
  • Power Conversion: The low forward voltage drop and high surge current capability make it suitable for DC-DC converters, motor control, and other power conversion applications.
  • Consumer Electronics: It is also used in various consumer electronics where efficient power management is crucial.
  • Telecommunications: The diode can be used in telecommunications equipment for power rectification and protection.

Q & A

  1. What is the part number of this Schottky diode?
    The part number is PMEG2020EPK,315.
  2. Who is the manufacturer of this component?
    The manufacturer is Nexperia USA Inc.
  3. What is the package type of this diode?
    The package type is 2-Pin DFN-D.
  4. What is the current rating of this diode?
    The current rating is 2 A.
  5. Is this diode AEC-Q101 qualified?
    Yes, it is AEC-Q101 qualified.
  6. What are the typical applications of this diode?
    Typical applications include automotive systems, power conversion, consumer electronics, and telecommunications.
  7. What are the key features of this diode?
    The key features include low forward voltage drop, high surge current capability, and compact packaging.
  8. What is the operating temperature range of this diode?
    The operating temperature range is typically -40°C to 150°C.
  9. Why is the DFN-D package beneficial?
    The DFN-D package is beneficial due to its compact size, thermal efficiency, and minimal footprint.
  10. Where can I purchase this component?
    You can purchase this component from distributors such as DigiKey, Mouser Electronics, and Arrow Electronics.

Product Attributes

Diode Type:Schottky
Voltage - DC Reverse (Vr) (Max):20 V
Current - Average Rectified (Io):2A
Voltage - Forward (Vf) (Max) @ If:450 mV @ 2 A
Speed:Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr):5 ns
Current - Reverse Leakage @ Vr:900 µA @ 20 V
Capacitance @ Vr, F:120pF @ 1V, 1MHz
Mounting Type:Surface Mount
Package / Case:2-XDFN
Supplier Device Package:DFN1608D-2
Operating Temperature - Junction:150°C (Max)
0 Remaining View Similar

In Stock

$0.40
474

Please send RFQ , we will respond immediately.

Similar Products

Part Number PMEG2020EPK,315 PMEG2010EPK,315
Manufacturer Nexperia USA Inc. Nexperia USA Inc.
Product Status Active Active
Diode Type Schottky Schottky
Voltage - DC Reverse (Vr) (Max) 20 V 20 V
Current - Average Rectified (Io) 2A 1A
Voltage - Forward (Vf) (Max) @ If 450 mV @ 2 A 415 mV @ 1 A
Speed Fast Recovery =< 500ns, > 200mA (Io) Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 5 ns 4 ns
Current - Reverse Leakage @ Vr 900 µA @ 20 V 600 µA @ 20 V
Capacitance @ Vr, F 120pF @ 1V, 1MHz 65pF @ 1V, 1MHz
Mounting Type Surface Mount Surface Mount
Package / Case 2-XDFN 2-XDFN
Supplier Device Package DFN1608D-2 DFN1608D-2
Operating Temperature - Junction 150°C (Max) 150°C (Max)
