Overview
The PBSS4480XZ is a bipolar junction transistor (BJT) produced by Nexperia USA Inc. This NPN transistor is designed for a variety of applications requiring high current and voltage handling capabilities. With its robust specifications and compact package, it is an ideal choice for many electronic circuits.
Key Specifications
| Parameter | Value |
|---|---|
| Transistor Polarity | NPN |
| Collector-Emitter Voltage (V ceo) | 80V |
| Transition Frequency (ft) | 150MHz |
| Power Dissipation (Pd) | 550mW |
| DC Collector Current | 4A |
| Package Type | SOT-89 (Surface Mount) |
Key Features
- High collector current of 4A, making it suitable for applications requiring substantial current handling.
- Collector-emitter voltage of 80V, providing robust voltage handling capabilities.
- Transition frequency of 150MHz, enabling its use in high-frequency applications.
- Compact SOT-89 surface mount package, ideal for space-saving designs.
- High power dissipation of 550mW, ensuring reliable operation in various environments.
Applications
- Power amplifiers and switches: Due to its high current and voltage ratings, it is suitable for power amplification and switching applications.
- Audio amplifiers: Can be used in audio circuits for amplifying signals without significant distortion.
- Industrial control: Suitable for controlling and driving loads such as relays, small motors, or LEDs in industrial settings.
- Automotive electronics: Can be used in automotive systems where high reliability and robust performance are required.
- RF circuits: Its high transition frequency makes it suitable for radio frequency applications such as amplification and modulation.
Q & A
- What is the collector-emitter voltage of the PBSS4480XZ transistor?
The collector-emitter voltage (V
ceo) of the PBSS4480XZ transistor is 80V. - What is the maximum DC collector current of the PBSS4480XZ transistor?
The maximum DC collector current of the PBSS4480XZ transistor is 4A. - What is the transition frequency of the PBSS4480XZ transistor?
The transition frequency (ft) of the PBSS4480XZ transistor is 150MHz. - What is the power dissipation of the PBSS4480XZ transistor?
The power dissipation (Pd) of the PBSS4480XZ transistor is 550mW. - What package type does the PBSS4480XZ transistor use?
The PBSS4480XZ transistor uses a SOT-89 surface mount package. - Is the PBSS4480XZ transistor suitable for high-frequency applications?
Yes, the PBSS4480XZ transistor is suitable for high-frequency applications due to its high transition frequency. - Can the PBSS4480XZ transistor be used in automotive electronics?
Yes, the PBSS4480XZ transistor can be used in automotive electronics due to its robust performance and reliability. - What are some common applications of the PBSS4480XZ transistor?
The PBSS4480XZ transistor is commonly used in power amplifiers, audio amplifiers, industrial control, and RF circuits. - Where can I purchase the PBSS4480XZ transistor?
The PBSS4480XZ transistor can be purchased from various distributors such as Digi-Key, Mouser Electronics, and Arrow Electronics. - What are the key benefits of using the PBSS4480XZ transistor?
The key benefits include high current and voltage handling, compact packaging, and high power dissipation, making it versatile for various applications.
