Overview
The BAV70QAZ is a dual common cathode high-speed switching diode produced by Nexperia. This component is encapsulated in a small DFN1010D-3 (SOT1215) package, making it ideal for applications where space is limited. The BAV70QAZ is designed for high-speed switching and offers several key benefits, including low leakage current, low capacitance, and high reverse voltage tolerance.
Key Specifications
| Parameter | Value | Unit |
|---|---|---|
| Type number | BAV70QA | - |
| Package | DFN1010D-3 (SOT1215) | - |
| Size | 1.1 x 1 x 0.37 | mm |
| Maximum reverse voltage (VR) | 100 | V |
| Maximum forward current (IF) | 300 | mA |
| Maximum forward voltage drop (VF) | 1250 @ IF=150mA | mV |
| Maximum leakage current (IR) | 500 @ VR=80V | nA |
| Maximum reverse recovery time (trr) | 4 | ns |
| Maximum capacitance (Cd) | 1.5 | pF |
| Configuration | Dual common cathode | - |
| Automotive qualified | Yes | - |
Key Features
- High switching speed with a reverse recovery time (trr) of ≤ 4 ns
- Low leakage current (IR) of ≤ 0.5 µA
- Low capacitance (Cd) of ≤ 1.5 pF
- High reverse voltage tolerance (VR) of up to 100 V
- Ultra small DFN1010D-3 (SOT1215) package for space-saving designs
- Automotive qualified, meeting AEC-Q100/Q101 standards
Applications
The BAV70QAZ is suitable for a wide range of applications across various industries, including:
- Automotive: For high-speed switching in automotive electronics, such as in power management and signal processing.
- Industrial: In industrial control systems, motor drives, and power supplies where high-speed switching is required.
- Consumer Electronics: In mobile and consumer devices where space is limited and high-speed switching is necessary.
- Power and Computing: In power management circuits, computing systems, and other high-speed applications.
Q & A
- What is the maximum reverse voltage of the BAV70QAZ?
The maximum reverse voltage (VR) of the BAV70QAZ is 100 V. - What is the package type of the BAV70QAZ?
The BAV70QAZ is packaged in a DFN1010D-3 (SOT1215) package. - What is the maximum forward current of the BAV70QAZ?
The maximum forward current (IF) of the BAV70QAZ is 300 mA. - Is the BAV70QAZ automotive qualified?
Yes, the BAV70QAZ is automotive qualified, meeting AEC-Q100/Q101 standards. - What is the reverse recovery time of the BAV70QAZ?
The reverse recovery time (trr) of the BAV70QAZ is ≤ 4 ns. - What is the maximum capacitance of the BAV70QAZ?
The maximum capacitance (Cd) of the BAV70QAZ is ≤ 1.5 pF. - What are the typical applications of the BAV70QAZ?
The BAV70QAZ is used in automotive, industrial, consumer electronics, power, and computing applications. - How small is the BAV70QAZ package?
The DFN1010D-3 (SOT1215) package of the BAV70QAZ measures 1.1 x 1 x 0.37 mm. - What is the maximum leakage current of the BAV70QAZ?
The maximum leakage current (IR) of the BAV70QAZ is ≤ 0.5 µA. - Where can I purchase the BAV70QAZ?
The BAV70QAZ can be purchased from Nexperia and its authorized distributors.
