Overview
The SN74LVC08ADBRE4 is a quad 2-input positive AND gate produced by Texas Instruments. This integrated circuit (IC) belongs to the Logic Gates category and is designed for use in a wide range of digital logic applications. It is part of the SN74LVC series, known for its low-voltage operation and high-speed performance. The SN74LVC08ADBRE4 is particularly suitable for applications requiring minimal power consumption and reliable logic operations, making it ideal for consumer electronics, industrial automation, and automotive systems. Its unique selling points include its compatibility with a wide voltage range, robust performance in harsh environments, and compact packaging.
Key Specifications
| Parameter | Value | Unit | Notes |
|---|---|---|---|
| Supply Voltage Range | 1.65 to 5.5 | V | Wide operating range |
| High-Level Output Current | -32 | mA | Strong drive capability |
| Low-Level Output Current | 32 | mA | Strong drive capability |
| Propagation Delay Time | 3.7 | ns | At 3.3V, typical |
| Operating Temperature Range | -40 to 125 | °C | Suitable for harsh environments |
| Package Type | SSOP-14 | - | Compact and space-saving |
| Logic Family | LVC | - | Low-voltage CMOS |
| Number of Inputs | 2 | - | Per gate |
| Number of Gates | 4 | - | Quad AND gate |
| Mounting Type | Surface Mount | - | Ideal for PCB integration |
Key Features
- Wide operating voltage range (1.65V to 5.5V) ensures compatibility with various systems.
- High-speed performance with a typical propagation delay of 3.7 ns at 3.3V.
- Low power consumption, making it suitable for battery-operated devices.
- Robust design with an operating temperature range of -40°C to 125°C.
- Compact SSOP-14 package for space-constrained applications.
- Strong drive capability (±32 mA) for reliable signal transmission.
Applications
The SN74LVC08ADBRE4 is widely used in various digital logic applications, including:
- Consumer Electronics: Used in smartphones, tablets, and gaming consoles for logic operations.
- Industrial Automation: Employed in control systems and PLCs for reliable signal processing.
- Automotive Systems: Integrated into vehicle control units for robust performance in harsh environments.
- Communication Systems: Utilized in networking equipment for high-speed logic operations.
- Embedded Systems: Ideal for microcontrollers and IoT devices due to its low power consumption.
Q & A
1. What is the operating voltage range of the SN74LVC08ADBRE4?
The operating voltage range is 1.65V to 5.5V.
2. What is the typical propagation delay of this IC?
The typical propagation delay is 3.7 ns at 3.3V.
3. Can this IC operate in harsh environments?
Yes, it has an operating temperature range of -40°C to 125°C.
4. What is the package type of the SN74LVC08ADBRE4?
It comes in an SSOP-14 package.
5. How many gates are included in this IC?
It includes four 2-input AND gates.
6. Is this IC suitable for battery-operated devices?
Yes, its low power consumption makes it ideal for such applications.
7. What is the output current capability of this IC?
It has a high-level output current of -32 mA and a low-level output current of 32 mA.
8. Can this IC be used in automotive systems?
Yes, it is designed for robust performance in automotive applications.
9. What is the logic family of this IC?
It belongs to the LVC (Low-Voltage CMOS) logic family.
10. Is this IC surface-mountable?
Yes, it is designed for surface-mount technology (SMT).
