Overview
The UPSD3254BV-24U6 is an 8-bit microcontroller produced by STMicroelectronics. This device is part of the UPSD3254 series and features an 8032 microcontroller core, making it suitable for a wide range of embedded system applications. The microcontroller includes integrated flash memory, various communication interfaces, and several peripherals, enhancing its functionality and versatility.
Key Specifications
| Specification | Value |
|---|---|
| Manufacturer | STMicroelectronics NV |
| Package | TQFP-80 |
| Core | 8032 |
| Program Memory Size | 288 kB |
| Data Bus Width | 8 bit |
| Maximum Clock Frequency | 24 MHz |
| Number of I/Os | 80 I/O |
| Data RAM Size | 32 kB |
| Supply Voltage - Min | 3 V |
| Supply Voltage - Max | 3.6 V |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Interface Type | DDC, I2C, UART, USB |
| Number of ADC Channels | 4 Channel |
| Number of Timers/Counters | 3 Timer |
| Mounting Style | SMD/SMT |
| Moisture Sensitive | Yes |
Key Features
- 8032 Microcontroller Core: The UPSD3254BV-24U6 is based on the 8032 microcontroller core, providing a robust and efficient processing environment.
- Flash Memory: It includes 288 kB of flash memory, allowing for extensive program storage and flexibility.
- Communication Interfaces: The device supports multiple communication interfaces such as DDC, I2C, UART, and USB, facilitating diverse application requirements.
- Peripherals: It features several peripherals including LVD (Low Voltage Detector), POR (Power-On Reset), PWM (Pulse Width Modulation), and WDT (Watchdog Timer), enhancing its functionality in various applications.
- ADC and Timers: The microcontroller includes 4-channel ADC and 3 timers/counters, which are essential for data conversion and timing tasks.
Applications
The UPSD3254BV-24U6 is suitable for a variety of embedded system applications, including:
- Industrial Automation: It can be used in industrial control systems, sensors, and actuators due to its robust peripherals and communication interfaces.
- Consumer Electronics: This microcontroller can be integrated into consumer electronics such as home appliances, gaming devices, and other electronic gadgets.
- Medical Devices: Its precision and reliability make it a good fit for medical devices that require accurate data processing and communication.
- Automotive Systems: It can be used in automotive systems for control and monitoring functions.
Q & A
- What is the core of the UPSD3254BV-24U6 microcontroller?
The core of the UPSD3254BV-24U6 is the 8032 microcontroller core. - What is the maximum clock frequency of the UPSD3254BV-24U6?
The maximum clock frequency is 24 MHz. - How much flash memory does the UPSD3254BV-24U6 have?
The device includes 288 kB of flash memory. - What communication interfaces does the UPSD3254BV-24U6 support?
The device supports DDC, I2C, UART, and USB interfaces. - What is the operating temperature range of the UPSD3254BV-24U6?
The operating temperature range is from -40°C to +85°C. - How many ADC channels does the UPSD3254BV-24U6 have?
The device has 4 ADC channels. - What is the package type of the UPSD3254BV-24U6?
The package type is TQFP-80. - Is the UPSD3254BV-24U6 moisture sensitive?
Yes, the UPSD3254BV-24U6 is moisture sensitive. - What peripherals are included in the UPSD3254BV-24U6?
The device includes LVD, POR, PWM, and WDT peripherals. - What is the data bus width of the UPSD3254BV-24U6?
The data bus width is 8 bits.
