STR912FAW46X6T
  • Share:

STMicroelectronics STR912FAW46X6T

Manufacturer No:
STR912FAW46X6T
Manufacturer:
STMicroelectronics
Package:
Tape & Reel (TR)
Description:
IC MCU 32BIT 1MB FLASH 128LQFP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Introduction

Overview

The STR912FAW46X6T is a 16/32-bit Flash Microcontroller (MCU) produced by STMicroelectronics. It is part of the STR9 family and features the ARM966E-S RISC core, which operates at a frequency of up to 96 MHz. This MCU is designed for applications requiring high performance, low power consumption, and a wide range of peripherals. The device includes integrated Ethernet, USB, CAN, and other communication interfaces, making it suitable for various industrial, automotive, and consumer electronics applications.

Key Specifications

SpecificationDetails
CoreARM966E-S RISC core, 5-stage pipeline, Harvard architecture
FrequencyUp to 96 MHz
Package128-TQFP
MemoryFlash memory (details vary by specific model, typically up to 512 KB)
RAMUp to 64 KB SRAM
PeripheralsEthernet, USB, CAN, ADC, UART, SPI, I2C, etc.
Power ManagementRun, Idle, and Sleep modes; dynamic clock control and gating
Supply VoltageVDD: 1.8V to 3.6V, VDDQ: 2.7V to 3.6V
Low Voltage DetectionLVD circuitry for voltage monitoring and brownout detection

Key Features

  • High-Performance Core: The ARM966E-S RISC core provides a 5-stage pipeline and Harvard architecture for efficient processing.
  • Low Power Consumption: Dynamic power management with Run, Idle, and Sleep modes to optimize power usage.
  • Integrated Peripherals: Includes Ethernet, USB, CAN, ADC, UART, SPI, and I2C for comprehensive communication and data conversion capabilities.
  • Independent A/D Converter Supply: Isolated analog voltage supply and ground connections for improved ADC performance.
  • System Supervisor: Monitors system and environmental inputs, generating resets or interrupts as needed.

Applications

The STR912FAW46X6T is versatile and can be used in a variety of applications, including:

  • Industrial Automation: For control systems, monitoring, and communication in industrial environments.
  • Automotive Systems: Suitable for vehicle control units, infotainment systems, and other automotive applications.
  • Consumer Electronics: Used in devices such as set-top boxes, gaming consoles, and other consumer electronic products.
  • Medical Devices: Can be applied in medical equipment requiring high reliability and performance.

Q & A

  1. What is the core architecture of the STR912FAW46X6T?
    The STR912FAW46X6T features the ARM966E-S RISC core with a 5-stage pipeline and Harvard architecture.
  2. What is the maximum operating frequency of the MCU?
    The maximum operating frequency is up to 96 MHz.
  3. What types of communication interfaces are integrated into the MCU?
    The MCU includes Ethernet, USB, CAN, UART, SPI, and I2C interfaces.
  4. How does the MCU manage power consumption?
    The MCU has dynamic power management with Run, Idle, and Sleep modes, and it can gate off individual clocks to peripherals.
  5. What is the purpose of the Low Voltage Detection (LVD) circuitry?
    The LVD circuitry monitors the supply voltage and generates early warning interrupts or resets if the voltage drops below the set thresholds.
  6. Can the ADC have an independent power supply?
    Yes, the ADC can have an isolated analog voltage supply and ground connections on certain packages.
  7. What are the typical applications of the STR912FAW46X6T?
    The MCU is used in industrial automation, automotive systems, consumer electronics, and medical devices.
  8. How does the system supervisor function in the MCU?
    The system supervisor monitors system and environmental inputs and can generate resets or interrupts based on configurable settings.
  9. What are the supply voltage ranges for the MCU?
    The supply voltage ranges are VDD: 1.8V to 3.6V and VDDQ: 2.7V to 3.6V.
  10. Is the MCU suitable for battery-powered applications?
    Yes, the MCU's power management features make it suitable for battery-powered applications, allowing for orderly shutdowns before batteries become too weak.

Product Attributes

Core Processor:ARM9®
Core Size:16/32-Bit
Speed:96MHz
Connectivity:CANbus, EBI/EMI, Ethernet, I²C, IrDA, Microwire, SPI, SSI, SSP, UART/USART, USB
Peripherals:Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Number of I/O:80
Program Memory Size:1MB (1M x 8)
Program Memory Type:Flash
EEPROM Size:-
RAM Size:96K x 8
Voltage - Supply (Vcc/Vdd):1.65V ~ 2V
Data Converters:A/D 8x10b
Oscillator Type:Internal
Operating Temperature:-40°C ~ 85°C (TA)
Mounting Type:Surface Mount
Package / Case:128-LQFP
Supplier Device Package:-
