Overview
The STPS2545CTY is a Schottky rectifier diode produced by STMicroelectronics. This component is designed for high-efficiency applications, particularly in the automotive sector. However, it is important to note that the STPS2545CTY is currently scheduled for obsolescence and will be discontinued by the manufacturer.
Key Specifications
| Parameter | Value |
|---|---|
| Package | TO-220AB |
| Maximum Average Rectified Current (I_O) | 2 x 12.5 A |
| Maximum Reverse Voltage (V_RRM) | 45 V |
| Forward Voltage Drop (V_F) | 0.57 V |
| Weight | 1.9 g |
Key Features
- High-efficiency Schottky rectifier diode
- Low forward voltage drop (V_F) of 0.57 V
- High maximum average rectified current (I_O) of 2 x 12.5 A
- Maximum reverse voltage (V_RRM) of 45 V
- Automotive-grade reliability
Applications
The STPS2545CTY is suitable for various high-power applications, particularly in the automotive sector. It is used in power supplies, DC-DC converters, and other systems where high efficiency and reliability are crucial.
Q & A
- What is the maximum average rectified current of the STPS2545CTY? The maximum average rectified current is 2 x 12.5 A.
- What is the forward voltage drop of the STPS2545CTY? The forward voltage drop is 0.57 V.
- What is the maximum reverse voltage of the STPS2545CTY? The maximum reverse voltage is 45 V.
- In what package is the STPS2545CTY available? The STPS2545CTY is available in the TO-220AB package.
- Is the STPS2545CTY still in production? No, the STPS2545CTY is scheduled for obsolescence and will be discontinued by the manufacturer.
- What are some common applications of the STPS2545CTY? It is commonly used in power supplies, DC-DC converters, and other high-power applications in the automotive sector.
- What is the weight of the STPS2545CTY? The weight of the STPS2545CTY is 1.9 g.
- Are there any substitutes available for the STPS2545CTY? Yes, STMicroelectronics suggests the STPS2545CT as a parametric equivalent.
- Why is the STPS2545CTY being discontinued? The reason for discontinuation is not specified, but it is part of the manufacturer's product lifecycle management.
- Where can I find detailed specifications for the STPS2545CTY? Detailed specifications can be found in the datasheet available on the STMicroelectronics website or through distributors like Mouser and Digi-Key.
