Product Introduction

Overview

The PMP5201Y is a 45 V, 100 mA PNP/PNP matched double transistor produced by Nexperia. It is packaged in a very small SOT363 (SC-88) Surface-Mounted Device (SMD) plastic package. This component is designed to provide high current gain matching and base-emitter voltage matching, making it suitable for various analog and digital applications.

Key Specifications

Parameter Conditions Min Max Unit
VCBO (collector-base voltage) open emitter - -50 V
VCEO (collector-emitter voltage) open base - -45 V
VEBO (emitter-base voltage) open collector - -5 V
IC (collector current) - -100 mA
ICM (peak collector current) tp ≤ 1 ms; single pulse -200 mA
Ptot (total power dissipation per transistor) Tamb ≤ 25 °C -200 mW
Ptot (total power dissipation per device) Tamb ≤ 25 °C -300 mW
Tj (junction temperature) - 150 °C
Tamb (ambient temperature) -65 to 150 - °C
Tstg (storage temperature) -65 to 150 - °C
hFE (current gain) - 200 to 450 -
hFE1 / hFE2 (current gain matching) - 0.98 -
VBE1 / VBE2 (base-emitter voltage matching) - 2 mV

Key Features

  • PNP/PNP matched double transistor in SOT363 (SC-88) SMD package.
  • High current gain matching (hFE1/hFE2 = 0.98).
  • Base-emitter voltage matching (VBE1/VBE2 = 2 mV).
  • Application-optimized pinout.
  • Suitable for current mirror and differential amplifier applications.
  • Automotive qualified.
  • RoHS compliant.

Applications

The PMP5201Y is versatile and can be used in a variety of applications, including:

  • Current mirrors.
  • Differential amplifiers.
  • Analog and digital circuits.
  • Automotive and industrial electronics.
  • Consumer and mobile devices.

Q & A

  1. What is the maximum collector-emitter voltage of the PMP5201Y?

    The maximum collector-emitter voltage (VCEO) is -45 V.

  2. What is the maximum collector current of the PMP5201Y?

    The maximum collector current (IC) is -100 mA.

  3. What is the package type of the PMP5201Y?

    The PMP5201Y is packaged in a SOT363 (SC-88) SMD plastic package.

  4. Is the PMP5201Y automotive qualified?
  5. What is the current gain matching of the PMP5201Y?

    The current gain matching (hFE1/hFE2) is 0.98.

  6. What is the base-emitter voltage matching of the PMP5201Y?

    The base-emitter voltage matching (VBE1/VBE2) is 2 mV.

  7. What are the typical applications of the PMP5201Y?

    The PMP5201Y is typically used in current mirrors, differential amplifiers, and various analog and digital circuits.

  8. Is the PMP5201Y RoHS compliant?
  9. What is the junction temperature range of the PMP5201Y?

    The junction temperature range is from -65°C to 150°C.

  10. What is the total power dissipation per transistor of the PMP5201Y?

    The total power dissipation per transistor (Ptot) is 200 mW at an ambient temperature of 25°C.

Product Attributes

Transistor Type:-
Current - Collector (Ic) (Max):-
Voltage - Collector Emitter Breakdown (Max):-
Vce Saturation (Max) @ Ib, Ic:-
Current - Collector Cutoff (Max):-
DC Current Gain (hFE) (Min) @ Ic, Vce:-
Power - Max:-
Frequency - Transition:-
Operating Temperature:-
Mounting Type:-
Package / Case:-
Supplier Device Package:-
0 Remaining View Similar

In Stock

$0.12
1,960

Please send RFQ , we will respond immediately.
