Overview
The MK70FN1M0VMJ15R is a 32-bit microcontroller from NXP USA Inc., part of the Kinetis K70 series. This microcontroller is based on the ARM® Cortex®-M4 CPU and integrates a central processing unit (CPU), memory, input/output peripherals, and programmable input/output pins. It is designed to offer high performance and power efficiency, making it suitable for a wide range of applications.
Key Specifications
| Specification | Value |
|---|---|
| Part Number | MK70FN1M0VMJ15R |
| Manufacturer | NXP USA Inc. |
| Package / Case | 256-LBGA |
| Operating Temperature | -40°C ~ 105°C |
| Supply Voltage | 1.71V ~ 3.6V |
| Speed | 120MHz |
| Flash Memory | 1MB (1M x 8) |
| RAM Size | 128K x 8 |
| Number of I/O | 128 |
| Oscillator Type | Internal |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Peak Reflow Temperature | 260°C |
Key Features
- ARM® Cortex®-M4 CPU for high performance and efficiency.
- Power optimization in various low-power modes based on application needs.
- Multi-master protection for the memory protection unit.
- Supports up to 128 request sources with a 32-channel DMA controller.
- External watchdog monitor and software vigilance.
- A wake-up unit with low leakage.
- Integrated peripherals including CANbus, EBI/EMI, Ethernet, I2C, IrDA, SD, SPI, UART/USART, USB, and USB OTG.
- ADC and DAC capabilities (e.g., 16-bit ADC, 12-bit DAC).
Applications
- Industrial automation and control systems.
- Medical devices requiring precise control and low power consumption.
- Consumer electronics such as smart home devices and appliances.
- Automotive systems, including infotainment and driver assistance.
- Internet of Things (IoT) devices and smart sensors.
Q & A
- What is the CPU type of the MK70FN1M0VMJ15R microcontroller?
The MK70FN1M0VMJ15R microcontroller is based on the ARM® Cortex®-M4 CPU.
- What is the maximum operating temperature of the MK70FN1M0VMJ15R?
The maximum operating temperature is 105°C.
- How much flash memory does the MK70FN1M0VMJ15R have?
The MK70FN1M0VMJ15R has 1MB (1M x 8) of flash memory.
- What is the supply voltage range for the MK70FN1M0VMJ15R?
The supply voltage range is 1.71V to 3.6V.
- Does the MK70FN1M0VMJ15R support low-power modes?
- What peripherals are integrated into the MK70FN1M0VMJ15R?
The microcontroller includes peripherals such as CANbus, EBI/EMI, Ethernet, I2C, IrDA, SD, SPI, UART/USART, USB, and USB OTG.
- What is the maximum speed of the MK70FN1M0VMJ15R?
The maximum speed is 120MHz.
- How many I/O pins does the MK70FN1M0VMJ15R have?
The microcontroller has 128 I/O pins.
- Is the MK70FN1M0VMJ15R RoHS compliant?
- What is the package type of the MK70FN1M0VMJ15R?
The package type is 256-LBGA.
