Overview
The LPC1227FBD48/301151 is a sophisticated microcontroller developed and manufactured by NXP USA Inc. This device is part of the LPC1200 series and is designed to meet the demands of advanced applications. It features an ARM® Cortex®-M0 core, making it highly efficient and versatile for various embedded system requirements.
Key Specifications
| Parameter | Specification |
|---|---|
| Part Number | LPC1227FBD48/301151 |
| Manufacturer | NXP USA Inc. |
| Description | IC MCU 32BIT 128KB FLASH 48LQFP |
| Package / Case | 48-LQFP (7x7) |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Speed | 45MHz |
| Number of I/O | 39 |
| Core Processor | ARM® Cortex®-M0 |
| RAM Size | 8K x 8 |
| Core Size | 32-Bit |
| Program Memory Size | 128KB (128K x 8) |
| Program Memory Type | FLASH |
| Connectivity | I²C, IrDA, Microwire, SPI, SSI, SSP, UART/USART |
| Peripherals | Brown-out Detect/Reset, DMA, POR, WDT |
| Data Converters | A/D 8x10b |
| Oscillator Type | Internal |
Key Features
- High-Performance Core: The LPC1227FBD48/301151 features an ARM® Cortex®-M0 core, providing high efficiency and low power consumption.
- Memory and Storage: It includes 128KB of FLASH memory and 8KB of RAM, making it suitable for a wide range of applications.
- Communication Interfaces: The device supports multiple communication interfaces such as I²C, IrDA, Microwire, SPI, SSI, SSP, and UART/USART.
- Peripherals: It includes peripherals like Brown-out Detect/Reset, DMA, POR, and WDT, enhancing its functionality and reliability.
- Operating Temperature Range: The microcontroller operates within a temperature range of -40°C to 85°C, making it suitable for various environmental conditions.
- Package and Mounting: It comes in a 48-LQFP (7x7) package and is surface mountable, facilitating easy integration into PCB designs.
Applications
The LPC1227FBD48/301151 is versatile and can be used in a variety of applications, including:
- Industrial Automation: For controlling and monitoring industrial processes.
- Consumer Electronics: In devices such as smart home appliances, wearables, and other consumer electronics.
- Medical Devices: For medical equipment that requires precise control and low power consumption.
- Automotive Systems: In automotive control units, sensors, and other automotive electronics.
- IoT Devices: For Internet of Things (IoT) applications that require efficient and reliable microcontrollers.
Q & A
- What is the core processor of the LPC1227FBD48/301151?
The core processor is an ARM® Cortex®-M0.
- What is the program memory size of the LPC1227FBD48/301151?
The program memory size is 128KB (128K x 8) FLASH.
- What are the communication interfaces supported by the LPC1227FBD48/301151?
The device supports I²C, IrDA, Microwire, SPI, SSI, SSP, and UART/USART.
- What is the operating temperature range of the LPC1227FBD48/301151?
The operating temperature range is -40°C to 85°C.
- What is the package type of the LPC1227FBD48/301151?
The package type is 48-LQFP (7x7).
- What are the peripherals included in the LPC1227FBD48/301151?
The peripherals include Brown-out Detect/Reset, DMA, POR, and WDT.
- What is the RAM size of the LPC1227FBD48/301151?
The RAM size is 8KB.
- Is the LPC1227FBD48/301151 RoHS compliant?
Yes, the LPC1227FBD48/301151 is RoHS compliant.
- What is the clock speed of the LPC1227FBD48/301151?
The clock speed is 45MHz.
- What are some typical applications of the LPC1227FBD48/301151?
Typical applications include industrial automation, consumer electronics, medical devices, automotive systems, and IoT devices.
