Overview
The PMEG2002AESF,315 is a Planar Maximum Efficiency General Application (MEGA) Schottky barrier rectifier produced by Nexperia USA Inc. This component is designed to offer high efficiency and reliability in various electronic applications. It features an integrated guard ring for stress protection, making it suitable for demanding environments.
Key Specifications
| Parameter | Value |
|---|---|
| Part Number | PMEG2002AESF,315 |
| Manufacturer | Nexperia USA Inc. |
| Description | DIODE SCHOTTKY 20V 200MA DSN0603-2 |
| Voltage - DC Reverse (Vr) (Max) | 20 V |
| Current - Average Rectified (Io) | 200 mA |
| Package / Case | DSN0603-2 |
| Mounting Type | Surface Mount |
| Diode Type | Schottky |
| RoHS Status | RoHS Compliant |
Key Features
- Low forward voltage drop (Vf) for high efficiency.
- Integrated guard ring for stress protection.
- Surface mount package (DSN0603-2) for compact design.
- Suitable for high-efficiency DC-to-DC conversion, switch-mode power supplies, and LED backlights.
- RoHS compliant, ensuring environmental sustainability.
Applications
The PMEG2002AESF,315 is versatile and can be used in a wide variety of applications, including:
- High-efficiency DC-to-DC conversion.
- Switch-mode power supplies.
- LED backlights for mobile devices and other electronic equipment.
- General purpose rectification in electronic circuits.
Q & A
- What is the maximum DC reverse voltage of the PMEG2002AESF,315?
The maximum DC reverse voltage is 20 V. - What is the average rectified current (Io) of this diode?
The average rectified current (Io) is 200 mA. - What type of package does the PMEG2002AESF,315 come in?
The package type is DSN0603-2. - Is the PMEG2002AESF,315 RoHS compliant?
Yes, it is RoHS compliant. - What are some common applications for this diode?
Common applications include high-efficiency DC-to-DC conversion, switch-mode power supplies, and LED backlights. - What is the mounting type of the PMEG2002AESF,315?
The mounting type is surface mount. - What is the diode type of the PMEG2002AESF,315?
The diode type is Schottky. - Does the PMEG2002AESF,315 have any integrated protection features?
Yes, it has an integrated guard ring for stress protection. - Where can I find the datasheet for the PMEG2002AESF,315?
You can find the datasheet on the Nexperia website or through authorized distributors like Digi-Key and Mouser. - Is the PMEG2002AESF,315 suitable for use in mobile devices?
Yes, it is suitable for use in mobile devices, particularly for LED backlights.
