Overview
The 74HCT151D-Q100,118 is an 8-bit multiplexer produced by Nexperia USA Inc. This component is part of the 74HCT series and is designed to operate within the TTL (Transistor-Transistor Logic) voltage range. It features eight binary inputs (I0 to I7), three select inputs (S0 to S2), and an enable input (E), allowing for the selection of one of the eight binary inputs to be routed to the complementary outputs (Y and Y'). The device is particularly useful in digital systems where data selection and routing are required.
Key Specifications
| Type number | VCC (V) | Logic switching levels | Output drive capability (mA) | tpd (ns) | Power dissipation considerations | Tamb (°C) | Package name |
|---|---|---|---|---|---|---|---|
| 74HCT151D-Q100,118 | 4.5 - 5.5 | TTL | ± 4 | 19 | Low | -40 ~ 125 | SO16 (SOT109-1) |
Key Features
- 8-bit Multiplexer: Selects one of eight binary inputs to be routed to the complementary outputs based on three select inputs and an enable input.
- TTL Compatibility: Operates with TTL logic levels, making it compatible with a wide range of digital systems.
- Low Power Dissipation: Designed for low power consumption, which is beneficial for energy-efficient designs.
- High Noise Immunity: Offers high noise immunity, ensuring reliable operation in noisy environments.
- ESD Protection: Features ESD protection exceeding 2000 V according to ANSI/ESDA/JEDEC JS-001 class 2.
- Wide Operating Temperature Range: Operates over a temperature range of -40°C to 125°C, making it suitable for various environmental conditions.
Applications
The 74HCT151D-Q100,118 is versatile and can be used in a variety of applications across different industries, including:
- Automotive Systems: For data selection and routing in automotive electronics.
- Industrial Control Systems: In industrial automation and control systems where data multiplexing is necessary.
- Consumer Electronics: In consumer devices that require digital data selection and routing.
- Computing and Networking: For data multiplexing in computing and networking equipment.
Q & A
- What is the primary function of the 74HCT151D-Q100,118?
The primary function is to act as an 8-bit multiplexer, selecting one of eight binary inputs to be routed to the complementary outputs based on three select inputs and an enable input.
- What is the voltage supply range for the 74HCT151D-Q100,118?
The voltage supply range is 4.5 V to 5.5 V.
- What type of logic levels does the 74HCT151D-Q100,118 operate with?
It operates with TTL (Transistor-Transistor Logic) levels.
- What is the output drive capability of the 74HCT151D-Q100,118?
The output drive capability is ± 4 mA.
- What is the propagation delay (tpd) of the 74HCT151D-Q100,118?
The propagation delay is approximately 19 ns.
- What is the operating temperature range of the 74HCT151D-Q100,118?
The operating temperature range is -40°C to 125°C.
- What type of package does the 74HCT151D-Q100,118 come in?
The device comes in an SO16 (SOT109-1) package.
- Does the 74HCT151D-Q100,118 have ESD protection?
Yes, it features ESD protection exceeding 2000 V according to ANSI/ESDA/JEDEC JS-001 class 2.
- Is the 74HCT151D-Q100,118 RoHS compliant?
Yes, it is RoHS compliant.
- What are some common applications for the 74HCT151D-Q100,118?
Common applications include automotive systems, industrial control systems, consumer electronics, and computing and networking equipment.
