Overview
The 74HC32DB,112-NEX is a quad 2-input OR gate integrated circuit manufactured by Nexperia USA Inc. This component is part of the 74HC series, known for its high-speed CMOS logic. It is designed to provide reliable and efficient logic operations in a variety of electronic systems.
Key Specifications
| Specification | Value |
|---|---|
| Manufacturer | Nexperia USA Inc. |
| Package | 14-SSOP (0.209", 5.30mm Width) |
| Series | 74HC |
| Logic Type | OR Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Voltage - Supply | 2 V ~ 6 V |
| Current - Quiescent (Max) | 2µA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Logic Level - Low | 0.5 V ~ 1.8 V |
| Logic Level - High | 1.5 V ~ 4.2 V |
| Max Propagation Delay @ V, Max CL | 15ns @ 6V, 50pF |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
Key Features
- High-speed CMOS logic with low power consumption.
- Quad 2-input OR gate configuration, providing four independent OR gates in a single package.
- Wide operating voltage range from 2 V to 6 V.
- Low quiescent current of 2µA.
- High output drive capability of ±5.2mA.
- Compact 14-SSOP package suitable for surface mount applications.
- Operating temperature range from -40°C to 125°C.
Applications
The 74HC32DB,112-NEX is versatile and can be used in a variety of applications, including:
- Digital logic circuits in consumer electronics.
- Industrial control systems requiring high-speed logic operations.
- Automotive electronics where reliability and low power consumption are crucial.
- Communication equipment and networking devices.
- Embedded systems and microcontroller projects.
Q & A
- What is the package type of the 74HC32DB,112-NEX?
The package type is 14-SSOP (0.209", 5.30mm Width). - What is the logic type of this component?
The logic type is OR Gate. - How many independent OR gates are included in this IC?
There are four independent OR gates. - What is the operating voltage range of the 74HC32DB,112-NEX?
The operating voltage range is from 2 V to 6 V. - What is the maximum propagation delay of this component?
The maximum propagation delay is 15ns @ 6V, 50pF. - What is the quiescent current of the 74HC32DB,112-NEX?
The quiescent current is 2µA. - What is the output drive capability of this IC?
The output drive capability is ±5.2mA. - What is the operating temperature range of this component?
The operating temperature range is from -40°C to 125°C. - Is the 74HC32DB,112-NEX RoHS compliant?
Yes, it is RoHS compliant. - What type of mounting is this component suitable for?
This component is suitable for surface mount applications.
