Overview
The HSP061-8M16 is a Transient Voltage Suppressor (TVS) diode produced by STMicroelectronics. This component is designed to provide protection against Electrostatic Discharge (ESD) and surge events in various electronic systems. Although the HSP061-8M16 is currently obsolete and no longer manufactured, it remains relevant for understanding and replacing similar components in existing designs.
Key Specifications
| Parameter | Value |
|---|---|
| Package Type | UQFN-16-EP (1.5x3.5 mm) |
| Clamping Voltage (Typical) | 14V |
| Peak Pulse Current (Ipp) @ 8/20µs | 3A |
| ESD Protection | Compliant with IEC 61000-4-2 (up to 15kV air discharge, 8kV contact) |
| Operating Temperature | -40°C to 150°C |
| RoHS Compliance | Yes |
Key Features
- High surge current capability: Up to 3A peak pulse current at 8/20µs.
- Low clamping voltage: Typical clamping voltage of 14V.
- Compact package: UQFN-16-EP (1.5x3.5 mm) for space-saving designs.
- Robust ESD protection: Compliant with IEC 61000-4-2 standards for ESD protection.
- Broad operating temperature range: -40°C to 150°C.
Applications
- Protection for high-speed interfaces: Such as USB, Ethernet, and other communication buses.
- Industrial and automotive systems: Suitable for use in harsh environments.
- Power line protection: Protects against transient surges and ESD events in power lines.
- Consumer electronics: Used in various consumer devices requiring ESD and surge protection.
Q & A
- What is the HSP061-8M16 used for?
The HSP061-8M16 is used for protecting electronic circuits against Electrostatic Discharge (ESD) and surge events.
- What is the typical clamping voltage of the HSP061-8M16?
The typical clamping voltage of the HSP061-8M16 is 14V.
- What is the peak pulse current rating of the HSP061-8M16?
The peak pulse current rating of the HSP061-8M16 is up to 3A at 8/20µs.
- Is the HSP061-8M16 RoHS compliant?
Yes, the HSP061-8M16 is RoHS compliant.
- What are the operating temperature limits of the HSP061-8M16?
The operating temperature range is from -40°C to 150°C.
- What package type does the HSP061-8M16 come in?
The HSP061-8M16 comes in a UQFN-16-EP package (1.5x3.5 mm).
- Is the HSP061-8M16 still in production?
No, the HSP061-8M16 is obsolete and no longer manufactured.
- What standards does the HSP061-8M16 comply with for ESD protection?
The HSP061-8M16 complies with IEC 61000-4-2 standards for ESD protection.
- What are some common applications of the HSP061-8M16?
Common applications include protection for high-speed interfaces, industrial and automotive systems, power line protection, and consumer electronics.
- Can the HSP061-8M16 be used in harsh environments?
Yes, the HSP061-8M16 is suitable for use in harsh environments due to its robust ESD protection and broad operating temperature range.
