Overview
The NUP4004M5T1G is a 5-pin bi-directional transient suppressor array designed and manufactured by onsemi. This component is specifically engineered to provide transient overvoltage protection in various electronic applications. It is part of onsemi's family of ESD (Electrostatic Discharge) protection diodes, ensuring robust protection against voltage spikes and other transient events.
Key Specifications
| Parameter | Value |
|---|---|
| Product Type | ESD Suppressors |
| Number of Pins | 5 |
| Directionality | Bi-directional |
| Diode Capacitance (Cd) | 23 pF |
| Voltage ESD Contact (Vesd) | 30 kV |
| Voltage ESD Air Gap (Vesd) | 30 kV |
Key Features
- Bi-directional transient suppressor array, providing protection in both directions.
- High ESD protection capability with 30 kV contact and air gap discharge ratings.
- Low capacitance of 23 pF, minimizing signal distortion.
- Compact 5-pin package, suitable for space-constrained applications.
- Designed to protect against transient overvoltage events, ensuring the reliability of electronic circuits.
Applications
The NUP4004M5T1G is suitable for a variety of applications that require robust ESD protection. These include:
- Consumer electronics such as smartphones, tablets, and laptops.
- Industrial control systems and automation equipment.
- Automotive electronics, including infotainment and navigation systems.
- Medical devices that require high reliability and protection against transient voltages.
- Communication devices, such as routers and switches.
Q & A
- What is the primary function of the NUP4004M5T1G?
The primary function of the NUP4004M5T1G is to provide transient overvoltage protection in electronic circuits. - What is the ESD protection rating of the NUP4004M5T1G?
The NUP4004M5T1G has an ESD protection rating of 30 kV for both contact and air gap discharges. - How many pins does the NUP4004M5T1G have?
The NUP4004M5T1G has 5 pins. - What is the capacitance of the NUP4004M5T1G?
The capacitance of the NUP4004M5T1G is 23 pF. - In which package is the NUP4004M5T1G available?
The NUP4004M5T1G is available in a compact 5-pin package. - What types of applications can the NUP4004M5T1G be used in?
The NUP4004M5T1G can be used in consumer electronics, industrial control systems, automotive electronics, medical devices, and communication devices. - Is the NUP4004M5T1G bi-directional?
Yes, the NUP4004M5T1G is a bi-directional transient suppressor array. - Where can I find detailed specifications for the NUP4004M5T1G?
Detailed specifications for the NUP4004M5T1G can be found in the datasheet available on the onsemi website or through distributors like Digi-Key and Mouser. - How does the NUP4004M5T1G protect against transient voltages?
The NUP4004M5T1G protects against transient voltages by clamping voltage spikes to a safe level, preventing damage to sensitive electronic components. - Is the NUP4004M5T1G suitable for high-reliability applications?
Yes, the NUP4004M5T1G is designed for high-reliability applications and is particularly useful in environments where transient voltage protection is critical.
