Overview
The NLU1G32AMUTCG is a single 2-input OR gate integrated circuit produced by onsemi. This component is designed for a wide range of digital logic applications, offering high performance and reliability. It is part of onsemi's logic IC family, known for its robust and versatile design.
Key Specifications
| Parameter | Value | Unit |
|---|---|---|
| Temperature Grade | MILITARY | |
| No. of Terminals | 6 | |
| Terminal Form | No Lead | |
| Package Type | UDFN6 | |
| DC Supply Voltage (VCC) | -0.5 to +6.5 | V |
| DC Input Voltage (VIN) | -0.5 to +6.5 | V |
| DC Output Voltage (VOUT) | -0.5 to VCC + 0.5 | V |
| Storage Temperature Range | -65 to +150 | °C |
| Junction Temperature Under Bias | +150 | °C |
Key Features
- Single 2-input OR gate logic function
- Wide operating voltage range: compatible with 1.65 V to 5.5 V supply
- Inputs/Outputs Overvoltage Tolerant up to 5.5 V
- Low propagation delay
- Pb-free, Halogen-free/BFR-free, and RoHS compliant
- Partial Power Down Protection (IOFF)
Applications
The NLU1G32AMUTCG is suitable for various digital logic applications, including but not limited to:
- General-purpose logic circuits
- Embedded systems
- Industrial control systems
- Automotive electronics
- Consumer electronics
Q & A
- What is the primary function of the NLU1G32AMUTCG?
The primary function is to act as a single 2-input OR gate. - What is the operating voltage range of the NLU1G32AMUTCG?
The operating voltage range is from 1.65 V to 5.5 V. - Is the NLU1G32AMUTCG RoHS compliant?
Yes, it is RoHS compliant. - What is the package type of the NLU1G32AMUTCG?
The package type is UDFN6. - What is the temperature grade of the NLU1G32AMUTCG?
The temperature grade is MILITARY. - Does the NLU1G32AMUTCG support partial power down protection?
Yes, it supports partial power down protection (IOFF). - What is the maximum junction temperature under bias for the NLU1G32AMUTCG?
The maximum junction temperature under bias is +150°C. - Is the NLU1G32AMUTCG Pb-free and Halogen-free/BFR-free?
Yes, it is Pb-free and Halogen-free/BFR-free. - What are some common applications of the NLU1G32AMUTCG?
Common applications include general-purpose logic circuits, embedded systems, industrial control systems, automotive electronics, and consumer electronics. - What is the storage temperature range for the NLU1G32AMUTCG?
The storage temperature range is -65°C to +150°C.
