Overview
The NL27WZ32USG is a high-performance dual 2-input OR Gate produced by onsemi. This component is designed to operate over a wide voltage range of 1.65 V to 5.5 V, making it versatile for various applications. It features low propagation delay, overvoltage tolerance, and partial power-down protection, ensuring reliable operation in diverse environments.
Key Specifications
| Parameter | Min | Typ | Max | Unit |
|---|---|---|---|---|
| DC Supply Voltage (VCC) | 1.65 | - | 5.5 | V |
| DC Input Voltage (VIN) | 0 | - | 5.5 | V |
| Propagation Delay (tPD) at VCC = 5 V | - | 2.5 ns | - | ns |
| Input Rise and Fall Time (tr, tf) | - | 3 ns | - | ns |
| Operating Temperature Range (TA) | -55 | - | 125 | °C |
| Output Source/Sink Current (IOUT) | - | - | ±50 mA | mA |
| Storage Temperature Range (TSTG) | -65 | - | 150 | °C |
Key Features
- Designed for 1.65 V to 5.5 V VCC operation
- Low propagation delay of 2.5 ns at VCC = 5 V (typ)
- Inputs/Outputs overvoltage tolerant up to 5.5 V
- IOFF supports partial power-down protection
- Source/Sink 24 mA at 3.0 V
- Available in US8, UDFN8, and UQFN8 packages
- Chip complexity < 100 FETs
- AEC-Q100 qualified and PPAP capable for automotive and other applications requiring unique site and control change requirements
- Pb-free, halogen-free/BFR-free, and RoHS compliant
Applications
The NL27WZ32USG is suitable for a wide range of applications, including automotive systems, industrial control systems, consumer electronics, and general-purpose logic circuits. Its wide operating voltage range and low power consumption make it an ideal choice for battery-powered devices and other low-power applications.
Q & A
- What is the operating voltage range of the NL27WZ32USG?
The NL27WZ32USG operates from 1.65 V to 5.5 V. - What is the typical propagation delay of the NL27WZ32USG at VCC = 5 V?
The typical propagation delay is 2.5 ns. - Is the NL27WZ32USG overvoltage tolerant?
Yes, the inputs and outputs are overvoltage tolerant up to 5.5 V. - What are the available package options for the NL27WZ32USG?
The component is available in US8, UDFN8, and UQFN8 packages. - Is the NL27WZ32USG AEC-Q100 qualified?
Yes, it is AEC-Q100 qualified and PPAP capable for automotive and other applications requiring unique site and control change requirements. - What is the maximum output source/sink current of the NL27WZ32USG?
The maximum output source/sink current is ±50 mA. - What is the storage temperature range of the NL27WZ32USG?
The storage temperature range is from -65°C to 150°C. - Is the NL27WZ32USG RoHS compliant?
Yes, it is Pb-free, halogen-free/BFR-free, and RoHS compliant. - What is the typical input rise and fall time of the NL27WZ32USG?
The typical input rise and fall time is 3 ns. - What are some common applications of the NL27WZ32USG?
Common applications include automotive systems, industrial control systems, consumer electronics, and general-purpose logic circuits.
