Overview
The UJA1163ATK/0Z is a mini high-speed CAN (Controller Area Network) System Basis Chip (SBC) developed by NXP USA Inc. This component is designed to comply with ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 standards, ensuring compatibility with high-speed CAN protocols. It integrates a CAN transceiver and other essential functions, making it a comprehensive solution for automotive and industrial applications requiring reliable CAN communication.
Key Specifications
| Parameter | Value |
|---|---|
| Compliance | ISO 11898-2:2016, SAE J2284-1 to SAE J2284-5 |
| Package Type | 14-pin HVSON |
| Operating Voltage | 4.5 V to 5.5 V |
| Operating Temperature | -40°C to 150°C |
| Standby Mode | Available |
| Data Rate | Up to 1 Mbps |
| Bus Pin ESD Protection | ±30 kV |
Key Features
- High-speed CAN transceiver compliant with ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 standards.
- Integrated System Basis Chip (SBC) with CAN transceiver and other essential functions.
- Standby mode for reduced power consumption.
- High bus pin ESD protection (±30 kV).
- Operating voltage range: 4.5 V to 5.5 V.
- Wide operating temperature range: -40°C to 150°C.
Applications
- Automotive systems: vehicle networks, engine control units, and other CAN-based communication systems.
- Industrial automation: control systems, sensors, and actuators requiring reliable CAN communication.
- Medical devices: equipment that requires robust and reliable communication protocols.
- Aerospace: systems that demand high reliability and compliance with stringent standards.
Q & A
- What is the UJA1163ATK/0Z used for? The UJA1163ATK/0Z is used as a high-speed CAN transceiver in various applications, including automotive, industrial, medical, and aerospace systems.
- What standards does the UJA1163ATK/0Z comply with? It complies with ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 standards.
- What is the package type of the UJA1163ATK/0Z? The package type is 14-pin HVSON.
- What is the operating voltage range of the UJA1163ATK/0Z? The operating voltage range is 4.5 V to 5.5 V.
- Does the UJA1163ATK/0Z have a standby mode? Yes, it has a standby mode for reduced power consumption.
- What is the maximum data rate supported by the UJA1163ATK/0Z? The maximum data rate is up to 1 Mbps.
- What is the bus pin ESD protection of the UJA1163ATK/0Z? The bus pin ESD protection is ±30 kV.
- What is the operating temperature range of the UJA1163ATK/0Z? The operating temperature range is -40°C to 150°C.
- Where can I find detailed specifications for the UJA1163ATK/0Z? Detailed specifications can be found in the datasheet available on NXP’s official website or through distributors like Mouser Electronics.
- Is the UJA1163ATK/0Z suitable for automotive applications? Yes, it is specifically designed for automotive and other high-reliability applications.
